Allen-Bradley PowerFlex 523 User Manual

Rockwell Automation Publication 520-UM001G-EN-E - September 2014 95
Programming and Parameters Chapter 3
Communications Group (continued)
C127 [RS485 Format]
Determines the details related to the specific Modbus protocol used by the drive. A reset or power cycle is required after selection is made.
Options 0 “RTU 8-N-1” (Default)
1“RTU 8-E-1”
2 “RTU 8-O-1”
3 “RTU 8-N-2”
4“RTU 8-E-2”
5 “RTU 8-O-2”
C128 [EN Addr Sel] Related Parameter(s): C129-C132, C133-C136, C137-C140
PowerFlex 525 only.
Enables the IP address, subnet mask and gateway address to be set with a BOOTP server. Identifies the connections that would be attempted on a reset or power cycle. A reset or power
cycle is required after selection is made.
Options 1 “Parameters”
2“BOOTP” (Default)
PF 525
C129 [EN IP Addr Cfg 1] Related Parameter(s): C128
C130 [EN IP Addr Cfg 2]
C131 [EN IP Addr Cfg 3]
C132 [EN IP Addr Cfg 4]
PowerFlex 525 only.
Sets the bytes in the IP address. A reset or power cycle is required after selection is made.
Values Default: 0
Min/Max: 0/255
Display: 1
PF 525
192.168.1.62
[EN IP Addr Cfg 1]
[EN IP Addr Cfg 2]
[EN IP Addr Cfg 3]
[EN IP Addr Cfg 4]
IMPORTANT
C128 [EN Addr Sel] must be set to 1 “Parameters”.

Allen-Bradley PowerFlex 523 Specifications

General

Frequency	50/60 Hz
Dimensions	Varies by model
Weight	Varies by model
Output Voltage	0 to Input Voltage
Power Rating	0.4-22 kW
Control Method	Sensorless Vector Control
Enclosure	IP20
Communication	EtherNet/IP
Operating Temperature	-20 to 50°C (-4 to 122°F)
Storage Temperature	-40 to 85°C (-40 to 185°F)
Relative Humidity	5% to 95% (non-condensing)
Input Voltage	200-240V AC, 380-480V AC
Horsepower	0.5…30 Hp
