62 Position Indexer/Speed Profiler
Profile Command Control Word
The profile/indexer is controlled with [Profile Command], parameter 705. The bit
definitions are as follows:
The bits in [Profile Command] can be set via DPI interface (HIM or Comm) or
digital inputs. When digital input(s) are programmed for “Pos Sel 1-5,” the starting
step of the profile is exclusively controlled by the digital inputs. The DPI interface
value for bits 0-4 will be ignored.
If a digital input is configured for bit 8-11 functions of the [Profile Command], the
DPI interface or the digital input can activate the command.
Velocity Regulated Step Parameters
Each of the Velocity Regulated steps has the following associated parameters or
functions:
X = Function not applicable to this step type
Bit Name Description
0 Start Step 0 The binary value of these bits determines which step will be the starting step
for the profile when a start command is issued. If the value of these bits are not
1-16 the drive will not run since it does not have a valid step to start from. Valid
Examples: 00011 = step 3, 01100 = step 12
1 Start Step 1
2 Start Step 2
3 Start Step 3
4 Start Step 4
5-7 Reserved Not used
8 Hold Step When set, this command will inhibit the profile from transitioning to the next
step when the condition(s) required are satisfied. When the Hold command is
released, the profile will transition to the next step.
9 Pos Redefine This bit is used to set the present position as Home. When this bit is set,
[Profile Status] bit “At Home” will be set and the [Units Traveled] will be set to
zero.
10 Find Home This bit is used to command the Find Home routine.
11 Vel Override When this bit is set the velocity of the present step will be multiplied by the
value in [Vel Override].
12-31 Reserved Not used.
Step Type
Time Time Blend
Digital
Input
Encoder
Incremental Blend
Parameter
Level End
Value To tal M ov e
Time
Total Time Digital Input
Number
Position & Direction Parameter
Number ±
X
Velocity Speed &
Direction
Speed &
Direction
Speed &
Direction
Speed Speed &
Direction
X
Accel Time Accel Rate Accel Rate Accel Rate Accel Rate Accel Rate X
Decel Time Decel Rate Decel Rate Decel Rate Decel Rate Decel Rate Decel Rate
Next Step
Condition
Time
greater than
[Step Value]
Time greater
than [Step
Value]
Digital Input
logic
At Position [Step
Value]
[Step Value]
> or < [Step
Dwell]
At Zero
transition
Dwell Dwell Time X Dwell Time X Compare
Value
Dwell Time
Batch Batch
Number
XBatch
Number
XXX
Next Next Step Next Step Next Step Next Step Next Step X (Stop)
