26 Rockwell Automation Publication 20A-IN009E-EN-P - January 2015
PowerFlex 70 Adjustable Frequency AC Drive
Table 8 - 208/240 Volt AC Three-phase Input Drive Ratings and Input Protection Devices
Cat.No.
Frame
(1)
Hp
Rating
Input
Ratings Output Amps
Dual
Element Time
Delay Fuse
Non-time
Delay Fuse
Circuit
Breaker
(4)
Motor
Circuit
Protector
(6)
140M Motor Protector with Adjustable Current Range
(7) (8)
ND HD Amps kVA Cont. 1 Min. 3 Sec. Min
(2)
Max
(3)
Min
(2)
Max
(3)
Max
(5)
Max
(5)
Available Catalog Numbers
(9)
Minimum
Enclosure Volume
(in.
3
)
(10)
208 Volt AC Input
20AB2P2 A 0.5 0.33 2.9 1.1 2.5 2.7 3.7 6 6 6 10 15 7 140M-C2E-B40 140M-D8E-B40 – 3441
20AB4P2 A 1 0.75 5.6 2 4.8 5.5 7.4 10 10 10 17.5 15 7 140M-C2E-B63 140M-D8E-B63 – 3441
20AB6P8 B 2 1.5 10 3.6 7.8 10.3 13.8 15 15 15 30 30 15 140M-C2E-C10 140M-D8E-C10 140M-F8E-C10 3441
20AB9P6 B 3 2 14 5.1 11 12.1 16.5 20 25 20 40 40 30 140M-C2E-C16 140M-D8E-C16 140M-F8E-C16 3441
20AB015 C 5 3 16 5.8 17.5 19.2 26.6 20 35 20 70 70 30 140M-C2E-C20 140M-D8E-C20 140M-F8E-C20 3441
20AB022 D 7.5 5 23.3 8.3 25.3 27.8 37.9 30 50 30 100 100 30 – 140M-D8E-C25 140M-F8E-C25 5098
20AB028 D 10 7.5 29.8 10.7 32.2 37.9 50.6 40 70 40 125 125 50 – – 140M-F8E-C32 5098
20AB042 D 15 10 39.8 14.3 43 55.5 74 60 100 60 175 175 70 – – 140M-F8E-C45 5098
20AB054 E 20 15 57.5 20.7 62.1 72.4 96.6 80 125 80 200 200 100 – – – –
20AB070 E 25 20 72.3 26.0 78.2 93.1 124 90 175 90 300 300 100 – – – –
240 Volt AC Input
20AB2P2 A 0.5 0.33 2.5 1.1 2.2 2.4 3.3 3 4.5 3 8 15 3 140M-C2E-B25 140M-D8E-B25 – 3441
20AB4P2 A 1 0.75 4.8 2 4.2 4.8 6.4 6 9 6 15 15 7 140M-C2E-B63 140M-D8E-B63 – 3441
20AB6P8 B 2 1.5 8.7 3.6 6.8 9 12 15 15 15 25 25 15 140M-C2E-C10 140M-D8E-C10 140M-F8E-C10 3441
20AB9P6 B 3 2 12.2 5.1 9.6 10.6 14.4 20 20 20 35 35 15 140M-C2E-C16 140M-D8E-C16 140M-F8E-C16 3441
20AB015 C 5 3 13.9 5.8 15.3 17.4 23.2 20 30 20 60 60 30 140M-C2E-C16 140M-D8E-C16 140M-F8E-C16 3441
20AB022 D 7.5 5 19.9 8.3 22 24.4 33 25 45 25 80 80 30 – 140M-D8E-C25 140M-F8E-C25 5098
20AB028 D 10 7.5 25.7 10.7 28 33 44 35 60 35 110 110 50 – – 140M-F8E-C32 5098
20AB042 D 15 10 38.7 16.1 42 46.2 63 50 90 50 150 150 50 – – 140M-F8E-C45 5098
20AB054 E 20 15 49.8 20.7 54 63 84 60 100 60 200 200 100 – – – –
20AB070 E 25 20 64.5 26.8 70 81 108 90 150 90 275 275 100 – – – –
See page 29
for notes.
Table 9 - 400/480 Volt AC Three-phase Input Drive Ratings and Input Protection Devices
Cat.No.
Frame
(1)
Hp
Rating
Input
Ratings Output Amps
Dual
Element Time
Delay Fuse
Non-time
Delay Fuse
Circuit
Breaker
(4)
Motor
Circuit
Protector
(6)
140M Motor Protector with Adjustable Current Range
(7) (8)
ND HD Amps kVA Cont. 1 Min. 3 Sec. Min
(2)
Max
(3)
Min
(2)
Max
(3)
Max
(5)
Max
(5)
Available Catalog Numbers
(9)
Minimum
Enclosure Volume
(in.
3
)
(10)
400 Volt AC Input
20AC1P3 A 0.37 0.25 1.6 1.1 1.3 1.4 1.9 3 3 3 5 15 3 140M-C2E-B16 – – 3441
20AC2P1 A 0.75 0.55 2.5 1.8 2.1 2.4 3.2 4 6 4 8 15 7 140M-C2E-B25 140M-D8E-B25 – 3441
20AC3P5 A 1.5 1.1 4.3 3 3.5 4.5 6 6 6 6 12 15 7 140M-C2E-B63 140M-D8E-B63 – 3441
20AC5P0 B 2.2 1.5 6.5 4.5 5 5.5 7.5 10 10 10 20 20 15 140M-C2E-C10 140M-D8E-C10 140M-F8E-C10 3441
20AC8P7 B 4 3 11.3 7.8 8.7 9.9 13.2 15 17.5 15 30 30 15 140M-C2E-C16 140M-D8E-C16 140M-F8E-C16 3441
20AC011 C 5.5 4 10.5 7.6 11.5 13 17.4 15 25 15 45 40 15 140M-C2E-C16 140M-D8E-C16 140M-F8E-C16 3441
20AC015 C 7.5 5.5 15.1 10.4 15.4 17.2 23.1 20 30 20 60 60 20 140M-C2E-C16 140M-D8E-C16 140M-F8E-C16 3441
20AC022 D 11 7.5 21.9 15.2 22 24.2 33 30 45 30 80 80 30 – 140M-D8E-C25 140M-F8E-C25 5098
20AC030 D 15 11 30.3 21 30 33 45 40 60 40 120 120 50 – – 140M-F8E-C32 5098
20AC037 D 18.5 15 35 24.3 37 45 60 50 80 50 125 140 50 – – 140M-F8E-C45 5098
20AC043 D 22 18.5 40.7 28.2 43 56 74 60 90 60 150 160 70 – – – –
20AC060 E 30 22 56.8 39.3 60 66 90 80 125 80 225 240 80 – – – –
20AC072 E 37 30 68.9 47.8 72 90 120 90 150 90 250 280 100 – – – –
480 Volt AC Input
20AD1P1 A 0.5 0.33 1.3 1.1 1.1 1.2 1.6 3 3 3 4 15 3 140M-C2E-B16 – – 3441
20AD2P1 A 1 0.75 2.4 2 2.1 2.4 3.2 3 6 3 8 15 3 140M-C2E-B25 140M-D8E-B25 – 3441
20AD3P4 A 2 1.5 3.8 3.2 3.4 4.5 6 6 6 6 12 15 7 140M-C2E-B40 140M-D8E-B40 – 3441
20AD5P0 B 3 2 5.6 4.7 5 5.5 7.5 10 10 10 20 20 15 140M-C2E-B63 140M-D8E-B63 – 3441
20AD8P0 B 5 3 9.8 8.4 8 8.8 12 15 15 15 30 30 15 140M-C2E-C10 140M-D8E-C10 140M-F8E-C10 3441
20AD011 C 7.5 5 9.4 7.9 11 12.1 16.5 15 20 15 40 40 15 140M-C2E-C16 140M-D8E-C16 140M-F8E-C16 3441
20AD014 C 10 7.5 12.4 10.4 14 16.5 22 20 30 20 50 50 20 140M-C2E-C16 140M-D8E-C16 140M-F8E-C16 3441
