Rockwell Automation Publication 20A-UM001N-EN-P - July 2013 103
HIM Overview Appendix B
Device Select Menu
Use this menu to access parameters in connected peripheral devices.
Memory Storage Menu
• Drive data can be saved to, or recalled from, User and HIM sets.
•User sets are files stored in permanent nonvolatile drive memory.
•HIM sets are files stored in permanent nonvolatile HIM memory.
Preferences Menu
The HIM and drive have features that you can customize.
Viewing and Editing
Parameters
The PowerFlex 70 drive is initially set to the basic parameter view. Parameter 196
[Param Access Lvl] controls the parameter views that you can see. The list below
describes the different settings and view options for Parameter 196
[Param Access Lvl]:
•View basic parameters – To view the basic parameters, set parameter 196
[Param Access Lvl] to option 0 “Basic”.
•View all parameters – To view all parameters, set parameter 196 [Param
Access Lvl] to option 1 “Advanced”.
• View engineering parameters – To view engineering parameters, set
parameter 196 [Param Access Lvl] to option 2 “Reserved”.
Refer to the PowerFlex 70/700 Reference Manual, publication PFLEX-RM004
for descriptions of these parameters. Parameter 196 is not affected by the Reset to
Defaults function.
Option Description
HIM Copycat
Device -> HIM
Device <- HIM
Save data to a HIM set, load data from a HIM set to active drive memory, or delete a HIM set.
Device User Sets Save data to a user set, load data from a user set to active drive memory, or name a user set.
Reset To Defaults Restore the drive to its factory-default settings.
Option Description
Drive Identity Add text to identify the drive.
Change Password Enable/disable or modify the password.
User Dspy Lines Select the display, parameter, scale and text for the user display. The user display is two lines
of user-defined data that appears when the HIM is not being used for programming.
User Dspy Time Set the wait time for the user display or enable/disable it.
User Dspy Video Select reverse or normal video for the frequency and user display lines.
Reset User Dspy Return all the options for the user display to factory default values.
