Programming and Parameters Chapter 1
Parameter Cross
Reference – by Name
Parameter Name Number Group Page
Accel Mask 281 Masks and
Owners
61
Accel Owner 293 Masks and
Owners
62
Accel Time X 140, 141 Ramp Rates 41
Alarm Config 1 259 Alarms 59
Alarm X @ Fault 229, 230 Diagnostics 57
Analog In X Hi 322, 325 Analog Inputs 65
Analog In X Lo 323, 326 Analog Inputs 65
Analog In X Loss 324, 327 Analog Inputs 65
Analog In1 Value 16 Metering 23
Analog In2 Value 17 Metering 23
Analog Out1 Hi 343 Analog
Outputs
67
Analog Out1 Lo 344 Analog
Outputs
67
Analog Out1 Sel 342 Analog
Outputs
66
Anlg In Config 320 Analog Inputs 65
Anlg In Sqr Root 321 Analog Inputs 65
Anlg Out Absolut 341 Analog
Outputs
66
Anlg Out Config 340 Analog
Outputs
66
Anlg Out1 Scale 354 Analog
Outputs
67
Anlg Out1 Setpt 377 Analog
Outputs
67
Auto Rstrt Delay 175 Restart Modes 46
Auto Rstrt Tries 174 Restart Modes 46
AutoMan Cnfg 192 HIM Ref Config 49
Autotune 61 Torq Attributes 27
Autotune Torque 66 Torq Attributes 28
Break Frequency 72 Volts per Hertz 30
Break Voltage 71 Volts per Hertz 29
Bus Reg Gain 160 Stop/Brake
Modes
43
Bus Reg Kd 165 Stop/Brake
Modes
44
Bus Reg Ki 160 Stop/Brake
Modes
43
Bus Reg Kp 164 Stop/Brake
Modes
44
Bus Reg Mode X 161, 162 Stop/Brake
Modes
44
Commanded Freq 2 Metering 22
Commanded Torque 24 Metering 23
Compensation 56 Torq Attributes 26
Control Status 440 Torq Attributes 29
Control SW Ver 29 Drive Data 23
Current Lmt Gain 149 Load Limits 41
Current Lmt Sel 147 Load Limits 41
Current Lmt Val 148 Load Limits 41
Current Rate Limit 154 Load Limits 42
Data In XX 300…307 Datalinks 63
Data Out XX 310…317 Datalinks 63
DB Resistor Type 163 Stop/Brake
Modes
44
DB While Stopped 145 Stop/Brake
Modes
42
DC Brake Level 158 Stop/Brake
Modes
43
DC Brake Lvl Sel 157 Stop/Brake
Modes
43
DC Brake Time 159 Stop/Brake
Modes
43
DC Bus Memory 13 Metering 23
DC Bus Voltage 12 Metering 23
Decel Mask 282 Masks and
Owners
61
Decel Owner 294 Masks and
Owners
62
Decel Time X 142, 143 Ramp Rates 41
Dig In Status 216 Diagnostics 55
Dig Out Setpt 379 Digital Outputs 69
Dig Out Status 217 Diagnostics 55
Dig OutX Level 381, 385 Digital Outputs 70
Dig OutX OffTime 383, 387 Digital Outputs 70
Dig OutX OnTime 382, 386 Digital Outputs 70
DigIn DataLogic 411 Digital Inputs 69
Digital InX Sel 361…366 Digital Inputs 68
Digital OutX Sel 380, 384 Digital Outputs 70
Direction Mask 279 Masks and
Owners
61
Direction Mode 190 Direction
Config
49
Direction Owner 291 Masks and
Owners
62
DPI Data Rate 270 Comm Control 60
DPI Port Select 274 Comm Control 61
DPI Port Value 275 Comm Control 61
DPI Ref Select 298 Comm Control 61
Drive Alarm X 211, 212 Diagnostics 53
Drive Checksum 203 Drive Memory 51
Drive Logic Rslt 271 Comm Control 60
Drive OL Count 219 Diagnostics 55
Drive OL Mode 150 Load Limits 41
Drive Ramp Rslt 273 Comm Control 60
Drive Ref Rslt 272 Comm Control 60
Drive Status 1, 2 209, 210 Diagnostics 52
Drive Status 3 222 Diagnostics 56
Drive Temp 218 Diagnostics 55
Droop RPM @ FLA 152 Stop/Brake
Modes
42
Dyn UserSet Actv 206 Drive Memory 52
Dyn UsrSet Cnfg 204 Drive memory 51
Dyn UsrSet Sel 205 Drive memory 51
Elapsed kWh 14 Metering 23
Elapsed MWh 9 Metering 22
Elapsed Run Time 10 Metering 23
Enc Pos Fdbk 414 Speed
Feedback
30
Encoder PPR 413 Speed
Feedback
30
Encoder Speed 415 Speed
Feedback
30
Fault Amps 225 Diagnostics 56
Fault Bus Volts 226 Diagnostics 56
Fault Clear 240 Faults 58
Fault Clear Mode 241 Faults 58
Fault Clr Mask 283 Masks and
Owners
61
Fault Clr Owner 295 Masks and
Owners
62
Fault Config 1 238 Faults 58
