Allen-Bradley PowerFlex 70 User Manual

Rockwell Automation Publication 20A-UM001N-EN-P - July 2013 63
Programming and Parameters Chapter 1
COMMUNICATION (file H)
Masks and Owners
297 [Local Owner]
Adapter that has requested exclusive control of all
drive logic functions. If an adapter is in local lockout,
all other functions (except stop) on all other adapters
are locked out and non-functional. Local control can
only be obtained when the drive is not running.
See P288 [Stop Owner].
276…
285
Datalinks
300
301
[Data In A1] - Link A Word 1
[Data In A2] - Link A Word 2
Parameter number whose value is written from a
communications device data table.
Parameters that can be changed only while drive is
stopped cannot be used as Datalink inputs. Entering
a parameter of this type disables the link.
Refer to your communications option manual for
datalink information.
Default:
Min/Max:
Units:
0 (0 = “Disabled”)
0/387
0/545
0/598
1
302
303
[Data In B1] - Link B Word 1
[Data In B2] - Link B Word 2
See [Data In A1] - Link A Word 1.
304
305
[Data In C1] - Link C Word 1
[Data In C2] - Link C Word 2
See [Data In A1] - Link A Word 1.
306
307
[Data In D1] - Link D Word 1
[Data In D2] - Link D Word 2
See [Data In A1] - Link A Word 1.
310
311
[Data Out A1] - Link A Word 1
[Data Out A2] - Link A Word 2
Parameter number whose value is written to a
communications device data table.
Default:
Min/Max:
Units:
0 (0 = “Disabled”)
0/387
0/545
0/598
1
312
313
[Data Out B1] - Link B Word 1
[Data Out B2] - Link B Word 2
See [Data Out A1] - Link A Word 1.
314
315
[Data Out C1] - Link C Word 1
[Data Out C2] - Link C Word 2
See [Data Out A1] - Link A Word 1.
316
317
[Data Out D1] - Link D Word 1
[Data Out D2] - Link D Word 2
See [Data Out A1] - Link A Word 1.
308 [HighRes Ref]
Used as a high resolution, 32 bit reference with
Datalinks.
±[Maximum Freq] or
±[Maximum Speed] = 2147418112
Default:
Min/Max:
Units:
0
±2147483647
1
090
093
126
128
213
298
File H Group No.
Parameter Name and Description
See page 14 for symbol descriptions
Values
Related
E C
E C v2
E C
E C v2
32
E C

Allen-Bradley PowerFlex 70 Specifications

General

Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Frequency Range	0 - 400 Hz
Humidity	5% to 95% non-condensing
Output Voltage	0 to Input Voltage
Control Methods	Sensorless Vector Control
Communications	Ethernet/IP, DeviceNet, ControlNet
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Ground Fault
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Enclosure Rating	IP20, NEMA Type 1
