Allen-Bradley PowerFlex 70 User Manual

Rockwell Automation Publication 20A-UM001N-EN-P - July 2013 7
Preface
The purpose of this manual is to provide you with the basic information needed
to program and troubleshoot the PowerFlex 70 Adjustable Frequency AC Drive.
About This Publication
This manual is intended for qualified pJulyersonnel. You must be able to program
and operate Adjustable Frequency AC Drive devices. In addition, you must have
an understanding of the parameter settings and functions.
What Is Not in This
Publication
This manual provides basic start-up, programming, and troubleshooting
information; it does not include information for mounting, wiring, and installing
the drive. For installation instructions, refer to the PowerFlex 70 Adjustable
Frequency AC Drive Installation Instructions, publication 20A-IN009
. For
detailed drive information, refer to the PowerFlex Reference Manuals,
publications PFLEX-RM001
and PFLEX-RM004.
Additional Resources
These documents contain additional information concerning related products
from Rockwell Automation.
Topic Page
About This Publication 7
What Is Not in This Publication 7
Additional Resources 7
Manual Conventions 8
Drive Frame Sizes 8
General Precautions 9
Catalog Number Explanation 11
Catalog Number Explanation (continued) 12
Resource Description
PowerFlex 70 Adjustable Frequency AC Drive Installation
Instructions, publication 20A-IN009
Provides the five basic steps needed to install and
perform a basic startup of the PowerFlex 70 drive.
PowerFlex 70 and 700 Reference Manual - Vol. 1,
publication PFLEX-RM001
Provides detailed information for specifications and
dimensions, operation, and dynamic brake selection for
the drive.
PowerFlex 70 Enhanced Control and 700 Vector Control
Reference Manual, publication PFLEX-RM004
Provides detailed drive information including
operation, parameter descriptions, and programming.
DriveGuard Safe-Off Option (Series B) for PowerFlex 40P and
PowerFlex 70 AC Drives, publication PFLEX-UM003
Provides information for the installation and operation
of the DriveGuard Safe Torque Off option.
PowerFlex Comm Adapter Manuals, publication
20COMM-UM
Provides information for the installation and operation
of the various communication protocol adapters
available for the drive.
PowerFlex Dynamic Braking Resistor Calculator Application
Technique, publication PFLEX-AT001
Provided information for determining dynamic braking
requirements and evaluating resistors for dynamic
braking.
Wiring and Grounding Guidelines for Pulse Width Modulated
(PWM) AC Drives, publication DRIVES-IN001
Provides the basic information needed to properly wire
and ground Pulse Width Modulated (PWM) AC drives.
