Preface
General Precautions
Qualified Personnel
Personal Safety
Product Safety
ATTENTION: Allow only qualified personnel familiar with adjustable frequency
AC drives and associated machinery to plan or implement the installation,
start-up and subsequent maintenance of the system. Failure to comply can
result in personal injury and/or equipment damage.
ATTENTION: To avoid an electric shock hazard, verify that the voltage on the
bus capacitors has discharged before performing any work on the drive.
Measure the DC bus voltage at the +DC terminal of the Power Terminal Block
and the -DC test point (refer to PowerFlex 70 Adjustable Frequency AC Drive
Installation Instructions, publication 20A-IN009
for locations). The voltage must
be zero.
ATTENTION: Risk of injury or equipment damage exists. DPI or SCANport host
products must not be directly connected together via 1202 cables.
Unpredictable behavior can result if two or more devices are connected in this
manner.
ATTENTION: The drive start/stop/enable control circuitry includes solid state
components. If hazards due to accidental contact with moving machinery or
unintentional flow of liquid, gas, or solids exist, an additional hardwired stop
circuit may be required to remove the AC line to the drive. An auxiliary braking
method may be required.
ATTENTION: An incorrectly applied or installed drive can result in component
damage or a reduction in product life. Wiring or application errors, such as,
undersizing the motor, incorrect or inadequate AC supply, or excessive ambient
temperatures can result in malfunction of the system.
ATTENTION: This drive contains ESD (Electrostatic Discharge) sensitive parts and
assemblies. Static control precautions are required when installing, testing,
servicing or repairing this assembly. Component damage can result if ESD
control procedures are not followed. If you are not familiar with static control
procedures, reference A-B publication 8000-4.5.2
, “Guarding Against
Electrostatic Damage” or any other applicable ESD protection handbook.
ATTENTION: Configuring an analog input for 0-20 mA operation and driving it
from a voltage source could cause component damage. Verify proper
configuration prior to applying input signals.
ATTENTION: A contactor or other device that routinely disconnects and
reapplies the AC line to the drive to start and stop the motor can cause drive
hardware damage. The drive is designed to use control input signals to start and
stop the motor. If an input device is used, operation must not exceed one cycle
per minute or drive damage can occur.
