Allen-Bradley PowerFlex 70 User Manual

Rockwell Automation Publication 20A-UM001N-EN-P - July 2013 23
Programming and Parameters Chapter 1
010 [Elapsed Run Time]
Accumulated time drive is outputting power.
Default:
Min/Max:
Units:
Read Only
0.0/429496729.5 Hrs
0.1 Hrs
011 [MOP Frequency]
Value of the signal at MOP (Motor Operated
Potentiometer).
Default:
Min/Max:
Units:
Read Only
±[Maximum Frequency]
0.1 Hz
194
195
012 [DC Bus Voltage]
Present DC bus voltage level.
Default:
Min/Max:
Units:
Read Only
0.0/Drive Rating Based
0.1 VDC
013 [DC Bus Memory]
6 minute average of DC bus voltage level.
Default:
Min/Max:
Units:
Read Only
0.0/Drive Rating Based
0.1 VDC
MONITOR (file A)
Metering
014 [Elapsed kWh]
Accumulated output energy of the drive.
Default:
Min/Max:
Units:
Read Only
0.0/429496729.5 kWh
0.1 kWh
015 [Torque Estimate]
Estimated motor torque output as percent of
motor rated torque.
Default:
Min/Max:
Units:
Read Only
±800.0%
0.1%
016
017
[Analog In1 Value]
[Analog In2 Value]
Value of the signal at the analog inputs.
Default:
Min/Max:
Units:
Read Only
0.000/20.000 mA
±10.000V
0.001 mA
0.001 Volt
320 …
327
022 [Ramped Speed]
The value shown is the value after the accel/
decel ramp but prior to any corrections supplied
by slip comp, PI, and so on
Default:
Min/Max:
Units:
Read Only
±500.0 Hz
0.1 Hz
023 [Speed Reference]
Summed value of ramped speed and Process PI.
Default:
Min/Max:
Units:
Read Only
±500.0 Hz
0.1 Hz
053
138
152
024 [Commanded Torque]
Final torque reference value after limits and
filtering are applied. % motor rated torque.
Default:
Min/Max:
Units:
Read Only
±800.0%
0.1%
053
025 [Speed Feedback]
Value of actual motor speed, measured by
encoder feedback or estimated.
Default:
Min/Max:
Units:
Read Only
±500.0 Hz
0.1 Hz
053
Drive Data
026 [Rated kW]
Drive power rating.
Default:
Min/Max:
Units:
Read Only
0.37/15.0 kW
0.00/300.00 kW
0.01 kW
027 [Rated Volts]
The drive input voltage class (208, 240, 400, and
so on.).
Default:
Min/Max:
Units:
Read Only
208/600 Volt
0.0/6553.5 Volt
0.1 VAC
028 [Rated Amps]
The drive rated output current.
Default:
Min/Max:
Units:
Read Only
1.1/32.2 Amps
0.0/6553.5 Amps
0.1 Amps
029 [Control SW Ver]
Main Control Board software version/firmware
revision.
Default:
Min/Max:
Units:
Read Only
0.000/65.256
0.0/65.535
0.001
196
File A Group No.
Parameter Name and Description
See page 14 for symbol descriptions
Values
Related
32
32
E C
E C v3
E C
E C
FV
E C v2
E C v2
32
E C
E C
E C
E C

Allen-Bradley PowerFlex 70 Specifications

General

Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Frequency Range	0 - 400 Hz
Humidity	5% to 95% non-condensing
Output Voltage	0 to Input Voltage
Control Methods	Sensorless Vector Control
Communications	Ethernet/IP, DeviceNet, ControlNet
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Ground Fault
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Enclosure Rating	IP20, NEMA Type 1
