INPUTS and OUTPUTS (file J)
Analog Outputs
343 [Analog Out1 Hi]
Sets the analog output value when the source
value is at maximum.
Default:
Min/Max:
Units:
10.00 Volts
0.00/10.00 Volts
0.00/20.00 mA
0.01 Volt
0.01 mA
340
342
344 [Analog Out1 Lo]
Sets the analog output value when the source
value is at minimum.
Default:
Min/Max:
Units:
0.00 Volts
0.00/10.00 Volts
0.00/20.00 mA
0.01 Volt
0.01 mA
340
342
354 [Anlg Out1 Scale]
Sets the high value for the range of analog out
scale. Entering 0.0 disables this scale and max
scale is used. Example: If [Analog Out Sel] =
“Commanded Trq,” a value of 150 = 150% scale in
place of the default 800%.
Default:
Min/Max:
Units:
0.0
[Analog Out1 Sel]
0.01
341
342
377 [Anlg Out1 Setpt]
Controls the analog output value from a
communication device.
Example
Set [Data In A1] to “377” as the value from the
communication device.
Default:
Min/Max:
Units:
0.00 Volts
0.00/10.00 Volts
0.00/20.00 mA
0.01 Volt
0.01 mA
340
File J Group No.
Parameter Name and Description
See page 14 for symbol descriptions
Values
Related
E C
E C
E C
E C
E C
E C
E C
E C

Allen-Bradley PowerFlex 70 Specifications

General

Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Frequency Range	0 - 400 Hz
Humidity	5% to 95% non-condensing
Output Voltage	0 to Input Voltage
Control Methods	Sensorless Vector Control
Communications	Ethernet/IP, DeviceNet, ControlNet
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Ground Fault
Operating Temperature	0°C to 50°C (32°F to 122°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Enclosure Rating	IP20, NEMA Type 1
