Appendix A
Supplemental Drive Information
For information on . . See page . .
Specifications
A-1
Communication Configurations A-4
Output Devices A-7
Drive, Fuse & Circuit Breaker Ratings A-7
Dimensions A-15
Frame Cross Reference A-22
Specifications
Category Specification
Agency
Certification
Listed to UL508C and CAN/CSA-C2.2 No. 14-M91.
Marked for all applicable European Directives
(1)
EMC Directive (89/336/EEC)
EN 61800-3 Adjustable Speed electrical power drive systems
Low Voltage Directive (73/23/EEC)
EN 50178 Electronic Equipment for use in Power Installations
Certified to AS/NZS, 1997 Group 1, Class A.
The drive is also designed to meet the following specifications:
NFPA 70 - US National Electrical Code
NEMA ICS 3.1 - Safety standards for Construction and Guide for Selection, Installation and
Operation of Adjustable Speed Drive Systems.
IEC 146 - International Electrical Code.
(1)
Applied noise impulses may be counted in addition to the standard pulse train causing erroneously
high [Pulse Freq] readings.
Category Specification
Protection Drive 200-208V 240V 380/400 480V 600V 690V
AC Input Overvoltage Trip: 247VAC 285VAC 475VAC 570VAC 690VAC
AC Input Undervoltage Trip: 120VAC 138VAC 233VAC 280VAC 345VAC
Bus Overvoltage Trip: 405VDC 405VDC 810VDC 810V DC 1013V DC
Bus Undervoltage Shutoff/Fault: 153V DC 153V DC 305V DC 305VDC 381VDC
Nominal Bus Voltage: 281VDC 324VDC 540VDC 648V DC 810V DC
All Drives
Heat Sink Thermistor: Monitored by microprocessor overtemp trip
Drive Overcurrent Trip
Software Overcurrent Trip:
Hardware Overcurrent Trip:
200% of rated current (typical)
220-300% of rated current (dependent on drive rating)
Line transients: up to 6000 volts peak per IEEE C62.41-1991
U
c
US
L
N223
