Allen-Bradley powerflex 700 User Manual

Supplemental Drive Information A-19
Figure A.7 PowerFlex 700 Bottom View Dimensions
Frame Rating Dimensions
0 All
1 All
2 All
132.9
(5.23)
187.5
(7.38)
30.2
(1.19)
41.9 (1.65)
56.1 (2.21)
96.0 (3.78)
75.9 (2.99)
96.0 (3.78)
55.0 (2.17)
75.0 (2.95)
35.0 (1.38)
22.2 (0.87) Dia. – 4 Places
185.0
(7.28)
133.3
(5.25)
187.6
(7.39)
25.5
(1.00)
70.0 (2.76)
43.0 (1.69)
96.0 (3.78)
75.9 (2.99)
108.5 (4.27)
67.5 (2.66)
47.5 (1.87)
87.5 (3.44)
22.2 (0.87) Dia.
3 Places
28.6 (1.13) Dia.
185.1
(7.29)
162.3
(6.39)
39.3 (1.55)
57.2 (2.25)
72.7 (2.86)
106.0 (4.17)
139.4 (5.49)
177.4 (6.98)
167.5 (6.59)
156.9 (6.18)
150.9
(5.94)
184.8
(7.28)
157.5
(6.20)
112.1
(4.41)
22.4 (0.88) Dia.
2 Places
28.7 (1.13) Dia.
3 Places

Allen-Bradley powerflex 700 Specifications

General

Series	PowerFlex 700
Category	AC Drive
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Enclosure	Type 1
Control Method	Sensorless Vector
Communication	EtherNet/IP, ControlNet, DeviceNet, PROFIBUS DP, Modbus
