Programming and Parameters 3-13
MONITOR
Metering
011 [MOP Frequency]
Value of the signal at MOP (Motor
Operated Potentiometer).
Default:
Min/Max:
Units:
Read Only
–/+[Maximum Freq]
0.1 Hz
079
[MOP Reference]
See description above.
Default:
Min/Max:
Units:
Read Only
–/+[Maximum Speed]
0.1 Hz
0.1 RPM
012 [DC Bus Voltage]
Present DC bus voltage level.
Default:
Min/Max:
Units:
Read Only
0.0/Based on Drive Rating
0.1 VDC
013 [DC Bus Memory]
6 minute average of DC bus voltage level.
Default:
Min/Max:
Units:
Read Only
0.0/Based on Drive Rating
0.1 VDC
014 [Elapsed kWh]
Accumulated output energy of the drive.
Default:
Min/Max:
Units:
Read Only
0.0/429496729.5 kWh
0.1 kWh
016
017
[Analog In1 Value]
[Analog In2 Value]
Value of the signal at the analog inputs.
Default:
Min/Max:
Units:
Read Only
0.000/20.000 mA
–/+10.000V
0.001 mA
0.001 Volt
022 [Ramped Speed]
Value of commanded speed after Accel/
Decel, and S-Curve are applied.
Default:
Min/Max:
Units:
Read Only
–/+400.0 Hz
–/+24000.0 RPM
0.1 Hz
0.1 RPM
079
023 [Speed Reference]
Summed value of ramped speed,
process PI and droop. When FVC Vector
mode is selected, droop will not be
added.
Default:
Min/Max:
Units:
Read Only
–/+400.0 Hz
–/+24000.0 RPM
0.1 Hz
0.1 RPM
079
024 [Commanded Torque]
Final torque reference value after limits
and filtering are applied. Percent of motor
rated torque.
Default:
Min/Max:
Units:
Read Only
–/+800.0%
0.1%
053
025 [Speed Feedback]
This parameter displays the value of
actual motor speed, whether measured
by encoder feedback, or estimated.
Default:
Min/Max:
Units:
Read Only
–/+400.0 Hz
–/+24000.0 RPM
0.1 Hz
0.1 RPM
File
Group
No.
Parameter Name & Description
See page 3-2 for symbol descriptions
Values
Related
Standard
Vector
Vector v3
Vector
Vector
FV
Vector
Vector
