Allen-Bradley PowerFlex 755T Product Information, Original Instructions

Rockwell Automation Publication 750-PC108A-EN-P - April 2021 13
PowerFlex 755T Drives Configured to Order Program Product Information
Input Power Fuses
In a configured input bay with AC line input protection using fuses, three input power fuses are used, one for each phase. For fuse specifications, see the following tables. For input power fuse locations, see Component and
Connection Locations on page 20.
Table 2 - Frame 8 Configured Input Bay AC Line Input Protection Fuses
Drive Fuses Drive Fuses
Input
Rating
Applied
Rating
Continuous
Output
Amps
Duty
Input
Amps
Cooper
Bussmann
(Manufacturer)
Part Number
Specification
Input
Rating
Applied
Rating
Continuous
Output
Amps
Duty
Input
Amps
Cooper
Bussmann
(Manufacturer)
Part Number
Specification
400V 160 kW 367 Light 352 LPJ-500SP CLASS J -600V, 500 A 480V 600 Hp 765 Light 704 170M6466 CLASS aR -690V, 1250 A
400V 160 kW 302 Normal 290 LPJ-400SP CLASS J -600V, 400 A 480V 600 Hp 710 Normal 653 170M6466 CLASS aR -690V, 1250 A
400V 160 kW 260 Heavy 250 LPJ-400SP CLASS J -600V, 400 A 480V 600 Hp 545 Heavy 501 170M6466 CLASS aR -690V, 1250 A
400V 200 kW 460 Light 442 LPJ-600SP CLASS J -600V, 600 A 480V 650 Hp 800 Light 736 170M6466 CLASS aR -690V, 1250 A
400V 200 kW 367 Normal 352 LPJ-500SP CLASS J -600V, 500 A 480V 650 Hp 740 Normal 681 170M6466 CLASS aR -690V, 1250 A
400V 200 kW 302 Heavy 290 LPJ-400SP CLASS J -600V, 400 A 480V 650 Hp 617 Heavy 568 170M6466 CLASS aR -690V, 1250 A
400V 250 kW 540 Light 518 170M6463 CLASS aR -690V, 900 A 600V 250 Hp 295 Light 271 LPJ-400SP CLASS J -600V, 400 A
400V 250 kW 460 Normal 442 LPJ-600SP CLASS J -600V, 600 A 600V 250 Hp 242 Normal 223 LPJ-350SP CLASS J -600V, 350 A
400V 250 kW 367 Heavy 352 LPJ-500SP CLASS J -600V, 500 A 600V 250 Hp 192 Heavy 177 LPJ-250SPI CLASS J -600V, 250 A
400V 315 kW 585 Light 562 170M6463 CLASS aR -690V, 900 A 600V 300 Hp 355 Light 327 LPJ-600SP CLASS J -600V, 600 A
400V 315 kW 540 Normal 518 170M6463 CLASS aR -690V, 900 A 600V 300 Hp 295 Normal 271 LPJ-400SP CLASS J -600V, 400 A
400V 315 kW 460 Heavy 442 LPJ-600SP CLASS J -600V, 600 A 600V 300 Hp 242 Heavy 223 LPJ-350SP CLASS J -600V, 350 A
400V 315 kW 650 Light 624 170M6466 CLASS aR -690V, 1250 A 600V 350 Hp 395 Light 363 LPJ-600SP CLASS J -600V, 600 A
400V 315 kW 585 Normal 562 170M6466 CLASS aR -690V, 1250 A 600V 350 Hp 355 Normal 327 LPJ-500SP CLASS J -600V, 500 A
400V 315 kW 472 Heavy 453 LPJ-600SP CLASS J -600V, 600 A 600V 350 Hp 295 Heavy 271 LPJ-400SP CLASS J -600V, 400 A
400V 355 kW 750 Light 720 170M6466 CLASS aR -690V, 1250 A 600V 400 Hp 435 Light 400 LPJ-600SP CLASS J -600V, 600 A
400V 355 kW 650 Normal 624 170M6466 CLASS aR -690V, 1250 A 600V 400 Hp 395 Normal 363 LPJ-500SP CLASS J -600V, 500 A
400V 355 kW 540 Heavy 518 170M6466 CLASS aR -690V, 1250 A 600V 400 Hp 355 Heavy 327 LPJ-500SP CLASS J -600V, 500 A
400V 400 kW 796 Light 764 170M6466 CLASS aR -690V, 1250 A 600V 450 Hp 51 Light 469 170M6463 CLASS aR -690V, 900 A
400V 400 kW 750 Normal 720 170M6466 CLASS aR -690V, 1250 A 600V 450 Hp 435 Normal 400 LPJ-600SP CLASS J -600V, 600 A
400V 400 kW 585 Heavy 562 170M6466 CLASS aR -690V, 1250 A 600V 450 Hp 395 Heavy 363 LPJ-500SP CLASS J -600V, 500 A
400V 400 kW 832 Light 799 170M6466 CLASS aR -690V, 1250 A 600V 500 Hp 580 Light 534 170M6463 CLASS aR -690V, 900 A
400V 400 kW 770 Normal 739 170M6466 CLASS aR -690V, 1250 A 600V 500 Hp 545 Normal 501 170M6463 CLASS aR -690V, 900 A
400V 400 kW 650 Heavy 624 170M6466 CLASS aR -690V, 1250 A 600V 500 Hp 450 Heavy 141 LPJ-600SP CLASS J -600V, 600 A
480V 250 Hp 361 Light 332 LPJ-500SP CLASS J -600V, 500 A 690V 200 kW 265 Light 243 170M6461 CLASS aR -690V, 700 A
480V 250 Hp 302 Normal 278 LPJ-400SP CLASS J -600V, 400 A 690V 200 kW 215 Normal 197 170M6461 CLASS aR -690V, 700 A
480V 250 Hp 248 Heavy 228 LPJ-400SP CLASS J -600V, 400 A 690V 200 kW 171 Heavy 157 170M6461 CLASS aR -690V, 700 A
480V 300 Hp 430 Light 396 LPJ-600SP CLASS J -600V, 600 A 690V 250 kW 330 Light 303 170M6461 CLASS aR -690V, 700 A
480V 300 Hp 361 Normal 332 LPJ-500SP CLASS J -600V, 500 A 690V 250 kW 265 Normal 243 170M6461 CLASS aR -690V, 700 A
480V 300 Hp 302 Heavy 278 LPJ-400SP CLASS J -600V, 400 A 690V 250 kW 215 Heavy 197 170M6461 CLASS aR -690V, 700 A
480V 350 Hp 485 Light 446 170M6463 CLASS aR -690V, 900 A 690V 315 kW 370 Light 340 170M6461 CLASS aR -690V, 700 A
480V 350 Hp 430 Normal 396 LPJ-600SP CLASS J -600V, 600 A 690V 315 kW 330 Normal 303 170M6461 CLASS aR -690V, 700 A
480V 350 Hp 361 Heavy 332 LPJ-500SP CLASS J -600V, 500 A 690V 315 kW 265 Heavy 243 170M6461 CLASS aR -690V, 700 A
480V 400 Hp 545 Light 501 170M6463 CLASS aR -690V, 900 A 690V 355 kW 415 Light 381 170M6461 CLASS aR -690V, 700 A
480V 400 Hp 505 Normal 465 170M6463 CLASS aR -690V, 900 A 690V 355 kW 370 Normal 340 170M6461 CLASS aR -690V, 700 A
480V 400 Hp 430 Heavy 396 LPJ-600SP CLASS J -600V, 600 A 690V 355 kW 330 Heavy 303 170M6461 CLASS aR -690V, 700 A
480V 450 Hp 617 Light 568 170M6466 CLASS aR -690V, 1250 A 690V 400 kW 460 Light 422 170M6463 CLASS aR -690V, 900 A
480V 450 Hp 545 Normal 501 170M6466 CLASS aR -690V, 1250 A 690V 400 kW 415 Normal 381 170M6463 CLASS aR -690V, 900 A
480V 450 Hp 454 Heavy 418 LPJ-600SP CLASS J -600V, 600 A 690V 400 kW 370 Heavy 340 170M6463 CLASS aR -690V, 900 A
480V 500 Hp 710 Light 653 170M6466 CLASS aR -690V, 1250 A 690V 500 kW 565 Light 519 170M6463 CLASS aR -690V, 900 A
480V 500 Hp 617 Normal 568 170M6466 CLASS aR -690V, 1250 A 690V 500 kW 505 Normal 464 170M6463 CLASS aR -690V, 900 A
480V 500 Hp 485 Heavy 446 170M6466 CLASS aR -690V, 1250 A 690V 500 kW 415 Heavy 381 170M6463 CLASS aR -690V, 900 A
