Allen-Bradley PowerFlex 755T Product Information, Original Instructions

14 Rockwell Automation Publication 750-PC108A-EN-P - April 2021
PowerFlex 755T Drives Configured to Order Program Product Information
Table 3 - Frame 9 Configured Input Bay AC Line Input Protection Fuses
Drive Fuses Drive Fuses
Input
Rating
Applied
Rating
Continuous
Output
Amps
Duty
Input
Amps
Cooper
Bussmann
(Manufacturer)
Part Number
Specification
Input
Rating
Applied
Rating
Continuous
Output
Amps
Duty
Input
Amps
Cooper
Bussmann
(Manufacturer)
Part Number
Specification
400V 500 kW 1040 Light 998 170M6470 CLASS aR -690V, 1800 A 600V 1000 Hp 980 Normal 901 170M6469 CLASS aR -690V, 1600 A
400V 500 kW 920 Normal 883 170M6470 CLASS aR -690V, 1800 A 600V 1000 Hp 825 Heavy 759 170M6469 CLASS aR -690V, 1600 A
400V 500 kW 770 Heavy 739 170M6470 CLASS aR -690V, 1800 A 690V 560 kW 650 Light 597 170M6466 CLASS aR -690V, 1250 A
400V 560 kW 1090 Light 1046 170M6470 CLASS aR -690V, 1800 A 690V 560 kW 565 Normal 519 170M6466 CLASS aR -690V, 1250 A
400V 560 kW 1040 Normal 998 170M6470 CLASS aR -690V, 1800 A 690V 560 kW 505 Heavy 464 170M6466 CLASS aR -690V, 1250 A
400V 560 kW 920 Heavy 883 170M6470 CLASS aR -690V, 1800 A 690V 630 kW 735 Light 675 170M6466 CLASS aR -690V, 1250 A
400V 630 kW 1182 Light 1135 170M6471 CLASS aR -690V, 2000 A 690V 630 kW 650 Normal 597 170M6466 CLASS aR -690V, 1250 A
400V 630 kW 1112 Normal 1067 170M6471 CLASS aR -690V, 2000 A 690V 630 kW 565 Heavy 519 170M6466 CLASS aR -690V, 1250 A
400V 630 kW 1040 Heavy 998 170M6471 CLASS aR -690V, 2000 A 690V 710 kW 820 Light 753 170M6466 CLASS aR -690V, 1250 A
400V 710 kW 1465 Light 1406 170M6471 CLASS aR -690V, 2000 A 690V 710 kW 735 Normal 675 170M6466 CLASS aR -690V, 1250 A
400V 710 kW 1175 Normal 1128 170M6471 CLASS aR -690V, 2000 A 690V 710 kW 650 Heavy 597 170M6466 CLASS aR -690V, 1250 A
400V 710 kW 1090 Heavy 1046 170M6471 CLASS aR -690V, 2000 A 690V 800 kW 920 Light 845 170M6469 CLASS aR -690V, 1600 A
400V 800 kW 1581 Light 1518 170M6471 CLASS aR -690V, 2000 A 690V 800 kW 820 Normal 753 170M6469 CLASS aR -690V, 1600 A
400V 800 kW 1463 Normal 1406 170M6471 CLASS aR -690V, 2000 A 690V 800 kW 735 Heavy 675 170M6469 CLASS aR -690V, 1600 A
400V 800 kW 1175 Heavy 1128 170M6471 CLASS aR -690V, 2000 A 690V 900 kW 1074 Light 986 170M6469 CLASS aR -690V, 1600 A
480V 700 Hp 960 Light 883 170M6470 CLASS aR -690V, 1800 A 690V 900 kW 920 Normal 845 170M6469 CLASS aR -690V, 1600 A
480V 700 Hp 800 Normal 736 170M6470 CLASS aR -690V, 1800 A 690V 900 kW 820 Heavy 753 170M6469 CLASS aR -690V, 1600 A
480V 700 Hp 740 Heavy 681 170M6470 CLASS aR -690V, 1800 A
480V 800 Hp 1045 Light 961 170M6470 CLASS aR -690V, 1800 A
480V 800 Hp 960 Normal 883 170M6470 CLASS aR -690V, 1800 A
480V 800 Hp 800 Heavy 736 170M6470 CLASS aR -690V, 1800 A
480V 900 Hp 1135 Light 1044 170M6471 CLASS aR -690V, 2000 A
480V 900 Hp 1045 Normal 961 170M6471 CLASS aR -690V, 2000 A
480V 900 Hp 960 Heavy 883 170M6471 CLASS aR -690V, 2000 A
480V 1000 Hp 1365 Light 1256 170M6471 CLASS aR -690V, 2000 A
480V 1000 Hp 1135 Normal 1044 170M6471 CLASS aR -690V, 2000 A
480V 1000 Hp 1045 Heavy 961 170M6471 CLASS aR -690V, 2000 A
480V 1100 Hp 1520 Light 1398 170M6471 CLASS aR -690V, 2000 A
480V 1100 Hp 1365 Normal 1256 170M6471 CLASS aR -690V, 2000 A
480V 1100 Hp 1135 Heavy 1044 170M6471 CLASS aR -690V, 2000 A
600V 600 Hp 690 Light 635 170M6466 CLASS aR -690V, 1250 A
600V 600 Hp 580 Normal 534 170M6466 CLASS aR -690V, 1250 A
600V 600 Hp 545 Heavy 501 170M6466 CLASS aR -690V, 1250 A
600V 700 Hp 760 Light 699 170M6466 CLASS aR -690V, 1250 A
600V 700 Hp 690 Normal 635 170M6466 CLASS aR -690V, 1250 A
600V 700 Hp 595 Heavy 547 170M6466 CLASS aR -690V, 1250 A
600V 800 Hp 825 Light 759 170M6466 CLASS aR -690V, 1250 A
600V 800 Hp 760 Normal 699 170M6466 CLASS aR -690V, 1250 A
600V 800 Hp 690 Heavy 635 170M6466 CLASS aR -690V, 1250 A
600V 900 Hp 980 Light 901 170M6469 CLASS aR -690V, 1600 A
600V 900 Hp 825 Normal 759 170M6469 CLASS aR -690V, 1600 A
600V 900 Hp 760 Heavy 699 170M6469 CLASS aR -690V, 1600 A
600V 1000 Hp 1102 Light 1014 170M6469 CLASS aR -690V, 1600 A
