Publication 2711-UM014B-EN-P
Specifications A-5
Character Sizes (Pixel size = 0.47 x 0.47 mm)
Environment
Operating Temperature 0 to 55° C (32 to 131° F)
Storage Temperature -20 to 70° C (-4 to 158° F)
Relative Humidity (non-condensing) 5 to 95% at 0 to 30° C (32 to 86° F)
5 to 75% at 31 to 40° C (88 to 104° F)
5 to 50% at 41 to 55° C (106 to 131° F)
Heat Dissipation 20 Watts (69 BTU/HR) for AC Power or DC Power
Impulse Shock (operating/non-operating) 30G/50G
Vibration (operating) 2G up to 2,000 Hz
Size in Pixels
width x height)
Characters/Row Maximum Rows Dimensions in mm
Width x Height
6 x 8 40 16 2.2 x 3.2
6 x 16 20 16 3.8 x 5.6
6 x 24 13 16 3.8 x 8.4
12 x 8 40 8 7.6 x 2.8
12 x 16 20 8 7.6 x 5.6
12 x 24 13 8 7.6 x 8.4
18 x 8 40 5 11.2 x 2.8
18 x 16 20 5 11.2 x 5.6
18 x 24 13 5 11.2 x 8.4
