Applying Power and Resetting Terminal
Chapter Objectives
This chapter provides information on:
• wiring and safety guidelines
• connecting AC or DC power
• resetting the terminal
• power-up sequence
Wiring and Safety
Guidelines
Use publication NFPA 70E, Electrical Safety Requirements for
Employee Workplaces when wiring the PanelView terminals. In
addition to the NFPA general guidelines:
• connect the terminal to its own branch circuit.
• the input power should be protected by a fuse or circuit breaker
rated at no more than 15 Amps.
• route incoming power to the PanelView terminal by a separate
path from the communications cable.
• where power and communication lines must cross, they should
cross at right angles. Communication lines can be installed in
the same conduit as low level DC I/O lines (less than 10 volts).
IMPORTANT
Do not run signal wiring and power wiring in
the same conduit.
DANGER
!
Explosion Hazard
• Substitution of components may impair suitability
for Class I, Division 2.
• Do not disconnect equipment unless power has
been switched off and area is known to be
non-hazardous.
• Do not connect or disconnect components unless
power has been switched off.
• All wiring must comply with N.E.C. article
501-4(b).
