Rockwell Automation Publication 1783-IN013B-EN-P - December 2019 15
Stratix 5800 Ethernet Managed Switches
Specifications
Stratix 5800 Switches, Series A
Attribute 1783-MMS10BE Series A 1783-MMS10E Series A 1783-MMS10 Series A, 1783-MMS10R Series A 1783-MMS10B Series A 1783-MMS10ER Series A
Temperature, operating
(1)
IEC 60068-2-1 (Test Ad, Operating Cold)
IEC 60068-2-2 (Test Bd, Operating Dry Heat)
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
(1) Operating temperature ratings apply to switches and any compatible expansion module.
-40 °C < Ta < +55 °C (-40 °F < Ta < +131 °F) -40 °C < Ta < +60 °C (-40 °F < Ta < +140 °F)
Temperature, surrounding air, max 55 °C (131 °F) 60 °C (140 °F)
Enclosure type rating None (open-style)
Power input, max 12…54V DC, 5.5 A 12…54V DC, 10.6 A 12…48V DC, 4.0 A 12…48V DC, 2.2 A 12…54V DC, 10.6 A
Alarm relay 30V DC, 1 A or 48V DC, 0.5 A
Wire size, Ethernet connections RJ45 connector according to IEC 60603-7, 2 or 4 pair Category 5e minimum cable according to TIA 568-B.1 or Category 5 cable according to ISO/IEC 24702
Wire size, power connections, max
0.5…0.8 mm
2
(20…18 AWG) solid or stranded, UL/CSA-rated style 1007, or 1569 twisted-pair copper appliance wiring material (AWM) wire (such as Belden part number
9318), 6.3 mm (0.25 in.) ± 0.5 mm (0.02 in.) strip length
Wire size, ground connection, max 4.0 mm
2
(12 AWG) minimum, stranded copper wire
Wire size, alarm connections, max
0.5…0.8 mm
2
(20…18 AWG) solid or stranded, UL/CSA-rated style 1007, or 1569 twisted-pair copper appliance wiring material (AWM) wire (such as Belden part number
9318), 6.3 mm (0.25 in.) ± 0.5 mm (0.02 in.) strip length
Screw torque, power terminals 0.565 N•m (5.0 in•lb)
Screw torque, power terminal captive screws 0.226 N•m (2.0 in•lb)
Screw torque, ground terminals, max 0.51 N•m (4.5 in•lb)
Screw torque, alarm terminals, max 0.23 N•m (2.0 in•lb)
Pilot duty rating Alarm not rated
North American temp code T4
ATEX temp code T4
Stratix 5800 Switches, Series B
Attribute 1783-MMS10BE Series B
1783-MMS10E Series B
1783-MMS10ER Series B
1783-MMS10 Series B
1783-MMS10R Series B
1783-MMS10B Series B
1783-MMS10EA Series B
1783-MMS10EAR Series B
Temperature, operating
(1)
IEC 60068-2-1 (Test Ad, Operating Cold)
IEC 60068-2-2 (Test Bd, Operating Dry Heat)
IEC 60068-2-14 (Test Nb, Operating Thermal Shock)
(1) Operating temperature ratings apply to switches and any compatible expansion module.
-40 °C < Ta < +60 °C (-40 °F < Ta < +140 °F)
Temperature, surrounding air, max 60 °C (140 °F)
Enclosure type rating None (open-style)
Power input, max 12…54V DC, 5.5 A 12…54V DC, 10.6 A 12…48V DC, 4.0 A 12…48V DC, 2.2 A 12…54V DC, 10.7 A
Alarm relay 30V DC, 1 A or 48V DC, 0.5 A
Wire size, Ethernet connections RJ45 connector according to IEC 60603-7, 2 or 4 pair Category 5e minimum cable according to TIA 568-B.1 or Category 5 cable according to ISO/IEC 24702
Wire size, power connections, max
0.5…0.8 mm
2
(20…18 AWG) solid or stranded, UL/CSA-rated style 1007, or 1569 twisted-pair copper appliance wiring material (AWM) wire (such as Belden part number
9318), 6.3 mm (0.25 in.) ± 0.5 mm (0.02 in.) strip length
Wire size, ground connection, max
4.0 mm
2
(12 AWG) minimum,
stranded copper wire
Wire size, alarm connections, max
0.5…0.8 mm
2
(20…18 AWG) solid or stranded, UL/CSA-rated style 1007, or 1569 twisted-pair copper appliance wiring material (AWM) wire (such as Belden part number
9318), 6.3 mm (0.25 in.) ± 0.5 mm (0.02 in.) strip length
Screw torque, power terminals 0.565 N•m (5.0 in•lb)
Screw torque, power terminal captive screws 0.226 N•m (2.0 in•lb)
Screw torque, ground terminals, max 0.51 N•m (4.5 in•lb)
Screw torque, alarm terminals, max 0.23 N•m (2.0 in•lb)
Pilot duty rating Alarm not rated
North American temp code T4
ATEX temp code T4
