allen SSE12 - Engine Mount Assembly Components

SECTION 4
PARTS
050362Page 46
PARTS LIST
U/MQTYDESCRIPTIONPART NO.ITEM
4
FSTN, HHCS 1/4-20 X 3/4
0100021
4FSTN, HHCS 3/8-16 X 1 3/4"
LONG GR8
0100392
4FSTN, HHCS 1/2-13 X 3/4 GR
5
0100663
3FSTN, HHCS 1/2-13 X 1 GR80100674
4
FSTN, FW 5/16
0100825
7
FSTN, FW 1/2 GR8
0100856
4
FSTN, LW 1/4010089
7
4
FSTN, LW 5/16
0100908
8FSTN, LW 3/80100919
8
FSTN, NUT HEX 3/8-16
01010210
1FSTN, NUT HEX 1/2-13 GR801010611
1
KEY, 3/16 SQ X 2
01027312
2RUBBER ISOLATOR, 2"
WITH 1/2-13 UNC
01272513
1DECAL,CAUTION KEEP
HANDS AWAY(SHAFT)
01289414
4FSTN, HHCS 5/16-24 X 3/401297415
1
DECAL, ALLOW ENG TO
COOL
01619116
12FSTN, FW HARD A325 3/8 (p)01775117
1
PULLEY, 2BK30X3/4 2 SET
SCREWS (p)
02069818
1
BRKT, ANGLE 5/8/11 HP
LOPRO
02787119
1
MOUNT, ENGINE 8/11 HP
LOPRO
027872-T20
1
GUARD, BELT 8/11 HP
LOPRO
02787721
1
BRKT, BELT GUARD LP
MOUNT
02787822
2
BUSHING, RUBBER SPLIT
02788323
4CLAMP, LOPRO ENGINE
MOUNT
02788424
4
SPACER, CLAMP LOPRO
ENG MT
02788525
1
V-BELT, 2BX - 40 GDY
03974526
1CLUTCH, 1" BORE 2 GRV
NR 1300
12600327
1ENGINE, 9 HP HONDA
GX270
04248128
4FSTN, HHCS 3/8-16 X 3-3/4
LONG GRADE 8 YELLOW
ZINC
02788238
28
1
7
21
14
26
10
9
18
25
24
2338
3
19
13
4
6
11
20
6
3
17
9
10
2
16
4.1 - Engine Mount, Illustration
