allen SSE12 - 5 Foot Section Components

SECTION 4
PARTS
050362Page 52
DETAIL A
SCALE .4
A
PARTS LIST
U/MQTYDESCRIPTIONPART NO.ITEM
4
FSTN, HHCS 1/2-13 X 3/4 GR
5
0100661
12FSTN, HHCS 1/2-13 X 1 GR80100672
12
FSTN, HHCS 1/2-13 X 1-1/4
GR 5
0100683
28
FSTN, NUT HEX 1/2-13 GR8
0101064
3PLUG, 1/4 NPT M. #P-28
PLASTIC
012401
5
1DECAL,CAUTION KEEP
HANDS AWAY(SHAFT)
0128946
2CAPLUG, RCL-16 (P)012899
7
1
SCREED TRUSS, 5' HED
WELDMENT (p)
0165658
6
FSTN, FW HARD A325 3/8 (p)
0177519
1
DECAL, DO NOT CROWN
W/O UJOINT
02004810
6
FSTN, NUT STOVER LOCK
3/8-16 (p)
02051411
1
SHAFT ASS'Y,5' STD HED
02219012
6FSTN, HHCS 3/8-16 X 1-1/2
GR 8
02840213
1DECAL, HEARING
PROTECTION (1")
03666914
1DECAL, MODEL 12 HED03750115
1
COUPLER, STEEL SCREED
LH TOP PIPE
03840016
3
COUPLER, STEEL SCREED
RH TOP PIPE
03840117
1TIE, 15.0 LG BLK STD
CABLE [
Ø3.000]
03935118
1DECAL, CE03989319
1
DECAL, RAZORBACK
TRUSS SCREED
04941320
1
DECAL, MADE IN USA (SP)
05344621
1DECAL AEC 1.5" X 3.25"
WHITE/RED
05633622
2BLADE, SCREED 5' 10GA10300123
1
BLADE, BULLFLOAT 5' 10GA
10500124
4PLATE, SPLICE 10GA10600125
1
JAM NUT RH (SX ED)
10800026
1JAM NUT LH (SX ED)10800127
1
SUPPORT, ED
INTERMEDIATE BRG
13500028
1ROD, STABILIZER 1/2-13 x
14" ZINC
13600029
4
NUT WHIZ 1/2-13NC ZP
190979030
3
2
1
2
3
30
4
3
2
2
2
3
23
23
25
25
24
25
28
12
8
26
7
17
10
6
21
20
15
14
1922
13
12
12
9
11
4.4 - 5 Foot Section, Illustration
