AM81687-A
Original Instructions – English
12
Removing the battery from the mower
1. Press and hold the battery release button
2. Remove the battery from the dock
Battery connection
IMPORTANT WARNING
The mower can operate on a single battery if necessary. One battery may be replaced with a fully
charged unit if required, all 4 batteries do not need to be replenished at the same time.
For the mower to operate correctly and to achieve the best performance:
• Always make sure there is a battery located in the end position (No. 4) on the operator’s
right-hand side.
• Try to make sure the battery in the end position (No. 4) on the operator’s right has an equal
or higher charge than the other batteries.
• When changing the batteries always swap the battery in the end position (No. 4) on the
operators right first.
