Alliance Laundry Systems DCB50EG - Page 89

M411429 91
Section 5 Service Procedures
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Figure 39
TMB1747S
REVERSING
TIMER
ASSEMBLY
TIMER
MOTOR
SWITCH
CONTROL
BOX
COVER
SCREW
GROUND
SCREW
GROUND
LUG
TRANSFORMER
(3 Phase Only)
COIL
(240 Volt)
SCREW
FAN
CONTACTOR
REVERSING
CONTACTOR
ASSEMBLY
REVERSING CONTROL ASSEMBLY
SOLID STATE
REVERSING TIMER
