Alliance Laundry Systems WF150 - Dimensions WF235, IWF235, IWF055, CWF235, CWF055

115 [4.53]
200 [7.88]
92 [3.62]
983 [38.68]
1121 [44.11]
1242 [48.9]
321 [12.64]
241 [9.49]
236 [9.29]
151 [5.94]
L
235 [9.25]
392 [15.41]
F
860 [33.86]
90 [3.54] 90 [3.54]680 [26.77]
1351 [53.19]
1376 [54.17]
500 [19.69]
50 [1.97] 282 [11.1] 518 [20.39] 50 [1.97]
49 [1.93]
241 [9.49]
14 [0.55] 984.5 [38.76]
927 [36.5]
900 [35.43]
3
19
 A. Ventilation soap dispenser
 B. Liquid soap connections
 C. Hard water connections 3/4"
 D. Warm water connections 3/4"
 E. Soft water connections 3/4"
 F. Main switch
 G.Electrical connections
 I. Ventilation tub
 K. Drain valve
 L. Steam connections
Dimensions WF235, IWF235, IWF055, CWF235, CWF055
Legend: metric mm [inches]
