Alliance Laundry Systems WF150 - Electrical Specifications WF305, IWF305, IWF075, CWF305, CWF075

4
39
WARNING
The washer-extractor should be connected to an individual branch
circuit not shared with lighting or other equipment.
4
Electrical Specications WF305, IWF305, IWF075, CWF305, CWF075
305 liters / 75 pounds
Boiler Fed/Steam Heat Electric Heat
Code
Voltage
Cycle
Phase
Wire
Full Load Amps
Recommended Circuit
Breaker (US-market)
AWG/mm2
kW Standard
Heating Elements
Full Load Amps
Recommended
Circuit Breaker (US-
market)
AWG/mm2
US NON-US US NON-US
N 440-480 50/60 3 3+PE 6 15 10 14/2.5
6x4 kW
32 50 50 8/10.0
P 380-415 50/60 3 3+N+PE 16 20 20 12/4.0 43 70 70 4/25.0
Q 200-240 50/60 3 3+PE 16 20 20 12/4.0
6x3 kW
60 70 70 4/25.0
X 200-240 50/60 1/3 2/3+PE 16 20 20 12/4.0 N/A N/A N/A N/A
Alternative Electric Heat Options
N 440-480 50/60 3 3+PE
3x3 kW +
3x4 kW
36 50 50 8/10.0
P 380-415 50/60 3 3+N+PE 48 70 70 4/25.0
Q 200-240 50/60 3 3+PE N/A N/A N/A N/A
X 200-240 50/60 1/3 2/3+PE N/A N/A N/A N/A
Table 6
