Alliance Laundry Systems WF150 - Dimensions WF400, IWF400, IWF090

70 [2.76] 850 [33.46] 70 [2.76]
990 [38.98]
500 [19.69]
1387 [54.59]
1412 [55.57]
7 [0.26]
248 [9.76]
71.5 [2.81]
67 [2.64] 347 [13.66] 46 [1.81]740 [29.13]
1200 [47.24]
1225 [48.23]
1283 [50.51]
1260 [49.61]
1024 [40.3]
115 [4.53]
488 [19.21]
368 [14.47]
247 [9.72]
268 [10.55]
98 [3.86]
264 [10.39]
311 [12.22]
187 [7.36]
1169 [46.02]
3
23
Dimensions WF400, IWF400, IWF090
Legend: metric mm [inches]
 A. Ventilation soap dispenser
 B. Liquid soap connections
 C. Hard water connections 3/4"
 D. Warm water connections 3/4"
 E. Soft water connections 3/4"
 F. Main switch
 G.Electrical connections
 I. Ventilation tub
 K. Drain valve
 L. Steam connections
