Alliance Laundry Systems WF150 - Page 42

Label 7
Label 8
Label 9
4
42
The 220V can be transformed to other values to drive other type soap pumps.
Example: pumps 24V ~. (See Label 7)
Also, pumps with different operating tension can be combined.
Example: 5 pumps 220V ~ and 1 pump 24V ~. (See Label 8)
With an external tension 24V DC (See Label 9)
