How to read Chart 1
To determine the correct three digit number required in
step four on the previous page, review the chart below.
Read Chart 1 from left to right. Each row begins with a
three digit number required in step four.
Each three digit number in the first column is followed
by the words ON or OFF in the following columns.
The word ON or OFF indicates if the option at the top
of that column is turned on or turned off when that
number is entered.
Chart 1: “Slg”
Signal
Value
High
Volume
Medium
Volume
Low
Volume
Unbalanced
Coin
Input
Cycle
End
Key
Pad
000 OFF OFF OFF OFF OFF OFF OFF
035 OFF OFF ON OFF OFF OFF ON
037 OFF OFF ON OFF OFF ON OFF
039 OFF OFF ON OFF OFF ON ON
041 OFF OFF ON OFF ON OFF OFF
043 OFF OFF ON OFF ON OFF ON
045 OFF OFF ON OFF ON ON OFF
047 OFF OFF ON OFF ON ON ON
049 OFF OFF ON ON OFF OFF OFF
051 OFF OFF ON ON OFF OFF ON
053 OFF OFF ON ON OFF ON OFF
055 OFF OFF ON ON OFF ON ON
057 OFF ON ON ON ON OFF OFF
059 OFF ON ON ON ON OFF ON
061 OFF ON ON ON ON ON OFF
063 OFF ON ON ON ON ON ON
065 OFF ON OFF OFF OFF OFF OFF
067 OFF ON OFF OFF OFF OFF ON
069 OFF ON OFF OFF OFF ON OFF
071 OFF ON OFF OFF OFF ON ON
073 OFF ON OFF OFF ON OFF OFF
075 OFF ON OFF OFF ON OFF ON
077 OFF ON OFF OFF ON ON OFF
079 OFF ON OFF OFF ON ON ON
081 OFF ON OFF ON OFF OFF OFF
083 OFF ON OFF ON OFF OFF ON
085 OFF ON OFF ON OFF ON OFF
087 OFF ON OFF ON OFF ON ON
089 OFF ON OFF ON ON OFF OFF
091 OFF ON OFF ON ON OFF ON
093 OFF ON OFF ON ON ON OFF
095 OFF ON OFF ON ON ON ON
129 ON OFF OFF OFF OFF OFF OFF
131 ON OFF OFF OFF OFF OFF ON
133 ON OFF OFF OFF OFF ON OFF
135 ON OFF OFF OFF OFF ON ON
137 ON OFF OFF OFF ON OFF OFF
Chart 1: (Page 1 of 2)
To Next Page
