7. Special Vend A End Time “SAE”
This option allows the user to set the time that Special
Vend A will end.
How to Program Special Vend A End Time
1. Control must be in Special Mode. Refer to Section
VII.
2. While pressing and holding the PERM PRESS
keypad with one hand, press the COLD keypad
with the other hand. Programmable option number
one, “SIg”, will appear in the VFD. See Figure 22.
3. Press the DELICATES (+) pad or the COLD (-)
pad to scroll through the programmable options
until “SAE” appears in the VFD. See Figure 23.
4. When “SAE” appears in the VFD, press the PERM
PRESS pad. The current end time (in military time)
will appear in the VFD.
5. Press the DELICATES (+) or the COLD (-) keypad
to increase or decrease the current hour to the
desired hour. See Figure 24.
6. Press the PERM PRESS (enter) keypad when the
correct hour appears in the VFD. The next option,
“SHC”, will appear in the VFD.
NOTE: To program “SHC” (Special Vend A Hot
Wash Number of Coins), see option 8. To program
other options, refer to the appropriate section.
How to Exit Programming Feature
1. Be sure service door has been opened and closed.
Refer to Section VI.
2. Be sure the control shows a programmable option,
not a value.
3. While pressing and holding the PERM PRESS
keypad with one hand; press the COLD keypad
with the other hand. The control will revert back to
the “Ready” mode. See Figure 2.
Figure 22
Figure 23
WASH
RINSE SOAK
SPIN
PRICE TIME REMAINING
INSERT COINS UNBALANCE
C105IE1A
WASH
RINSE SOAK
SPIN
PRICE TIME REMAINING
INSERT COINS UNBALANCE
C112IE1A
Figure 24
NORMAL
HOT
DELICATES
COLD
PERM
PRESS
WARM
Press this pad (enter)
to choose a selected
value or option
Press this pad (+)
to scroll forward or
increase a value
Press this pad (-)
to scroll back or
decrease a value
C106IE1A
