13
Appendix A
Technical Specifications
Physical Characteristics
Dimensions: 232 x 142 x 43 mm
Weight: 1.2 Kg
Operating temperatures: 0° to 40° C
Storage temperatures: -30°
to 60° C
Relative humidity: 5% to 95% non-condensing
Number of ports: 4 x 10/100 Mbps ports
Media interface exchange: MDI RJ45 shared with port 1X
Agency Compliance
Standard: IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX Fast Ethernet
ANSI/IEEE Std 802.3 Auto-Negotiation
IEEE 802.3 Frame types: Transparent
IEEE 802.3 MAC layer frame size: 64 - 1518
Bytes
EMI/RFI: FCC Class A, CE Class A, VCCI Class A
Immunity: EN 50082-1
Safety: Complies with safety standards UL 1950,
CSA 950, TUV/GS EN60950
