Installation
18
Figure 11: Switches as Uplink to the Backbone
Sales
Engineering
Finance
Formula 8200 Switch
AT-FS708 Switch
SNMP station
CORPORATE BACKBONE
MIS
AT-FS708 Switch
AT-FS708 Switch
Hub
Hub
Hub
