Allied 4DHV Mini-Split Series - Capacity Data; Cooling and Heating Capacity - 12 (208;230 V)

508067-01 Issue 2016 Page 15 of 75
COOLING CAPACITY - 09 (208/230V)
Outdoor
Temperature - °F
(Dry Bulb)
Indoor Temperature - °F (Dry Bulb / Wet Bulb)
65°F / 54°F 70°F / 59°F 75°F / 63°F 80°F / 67°F
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
Total
mBtuh
Sensible
mBtuh
–13 7.13 5.07 7.38 5.22 7.97 5.67 8.43 5.94
–5 7.62 5.45 7.98 5.74 8.62 6.16 9.07 6.47
–4 7.73 5.65 8.19 5.96 8.79 6.43 9.25 6.71
0 8.13 5.71 8.52 5.98 9.35 6.57 9.74 6.82
5 8.42 6.03 8.93 6.47 9.64 6.91 10.15 7.26
15 8.50 6.22 9.12 6.74 9.89 7.24 10.30 7.54
25 8.73 5.94 9.20 6.20 9.93 6.76 10.46 7.04
35 8.97 6.18 9.39 6.44 10.08 6.95 10.61 7.33
45 9.04 6.17 9.42 6.45 10.23 6.98 10.77 7.31
55 9.12 6.63 9.61 6.99 10.49 7.62 10.92 7.90
65 9.25 6.74 9.75 7.10 10.52 7.66 11.08 8.07
75 9.50 6.66 9.95 6.97 10.62 7.45 11.24 7.88
85 9.58 6.81 10.04 7.09 10.84 7.71 11.41 8.04
95 9.71 7.15 10.29 7.58 10.99 8.09 11.62 8.69
105 9.12 7.12 9.62 7.50 10.38 8.10 10.93 8.52
110 8.58 7.29 9.09 7.73 9.71 8.25 10.27 8.73
115 8.01 7.13 8.50 7.56 9.17 8.16 9.66 8.59
122 7.43 6.83 7.87 7.24 8.54 7.85 8.89 8.18
HEATING CAPACITY - 09 (208/230V)
Outdoor
Temperature - °F
(Dry Bulb)
Indoor Temperature - °F (Dry Bulb)
60°F 65°F 70°F 75°F
Total
mBtuh
Total
mBtuh
Total
mBtuh
Total
mBtuh
–13 5.86 5.67 5.37 5.12
–5 6.98 6.75 6.39 6.10
0 8.10 7.84 7.41 7.11
5 8.96 8.69 8.23 7.94
17 10.80 10.48 9.91 9.52
19.4 10.86 10.53 9.96 9.56
24.8 10.94 10.61 10.02 9.67
32 10.98 10.67 10.07 9.56
35 11.10 10.73 10.16 9.60
39.2 11.61 11.23 10.62 10.14
44.6 12.56 12.14 11.47 11.01
47 13.11 12.58 11.96 11.54
53.6 13.55 13.00 12.35 11.86
57 13.82 13.34 12.66 12.03
