Allied 4DHV Mini-Split Series - Dimensions; Outdoor Units

508067-01 Issue 2016 Page 5 of 75
19-1/8 (486)
2-3/4
(70)
11-7/8 (302)
21-7/8
(556)
30-3/8 (772)
30-5/8 (778)
2-1/2
(64)
1/2 (13)
1/2
(13)
4DHV1S09S
BOTTOM VIEW
FRONT VIEWSIDE VIEW
SIDE VIEW
12-5/8
(322)
11-1/4
(286)
2-3/8 (60)
3-5/8 (92)
DRAIN HOLE (bottom of unit)
11-3/4
(298)
BOTTOM VIEW
FRONT VIEW
SIDE VIEW
SIDE VIEW
4DHV1S12S, 4DHV1S18S
2-3/8 (60)
3/4
(19)
14-3/8
(365)
12-1/4
(311)
13-3/
8
(340)
2-3/8 (60)
3-3/8 (86)
21-7/8
(556)
1/2
(13)
20-1/4 (514)
31-1/2 (800)
31-1/2 (815)
13-1/8 (333)
2-3/4
(70)
Dimensions - Outdoor Units - Inches (MM)
