Model Number DWH109S4 DWH112S4 DWH118S4 DWH124S4 DWH136S4
Nominal Size- Tons 0.75 1 1.5 2 3
Electrical Char.
60 Hz - 1 Phase 115V 208/230V 115V 208/230V 208/230V 208/230V 208/230V
Rated Load
Amps
0.7 0.06 0.7 0.06 0.11 0.37 0.5
Input (W) 35.2 50 35.2 50 36 116 72
Output (W) 20 30 60
Room Temp
Range (°F)
Cooling 62 - 90
Heating 32 - 86
Air Volume
(CFM)
High/Med/Low 247/182/129 309/285/187 294/212/171 324/282/212 449/393/262 706/588/450 794/647/500
Sound Data
(dBA)
High/Med/Low 38 / 32 / 25 38 / 30 / 28 38 / 32 / 24 43 / 35 / 30.5 48 / 42.5 / 34 48.5 / 44 / 38
Connections
(in.)
Liquid/Gas -
O.D. - Flare
1/4” / 3/8” 1/4” / 1/2” 1/4” / 1/2” 3/8” / 5/8”
Drain - O.D. 1 0.69
Weight (lbs.) Net/ Packaging 18 / 23 19 / 25 25 / 33 31 / 40 40 / 50
Specications - Wall Mounted Indoor Units
