Allied 4DHV Mini-Split Series - Model Number Identification

508067-01Issue 2016Page 2 of 75
Model Number Identication
4 D HV 1 S 09 S -1 P4 D HV 1 S 09 S -1 P
VOLTAGE
L = 115V-1 PHASE-60HZ
P = 208/230-1 PHASE-60HZ
MINOR DESIGN SEQUENCE
1 = 1ST REVISION
REFRIGERANT CIRCUITS
S = SINGLE CIRCUITS
NOMINAL COOLING CAPACITY
09 = .75 TONS
12 = 1 TONS
18 = 1.5 TONS
24 = 2 TONS
36 = 3 TONS
REFRIGERANT TYPE
R410A
SERIES TYPE
D = DUCTLESS
UNIT TYPE
HV = HEAT PUMP
MAJOR DESIGN SEQUENCE
1 = 1ST GENERATION
COOLING CAPACITY
S = STANDARD EFFICIENCY
OUTDOOR SINGLE-ZONE HEAT
PUMP UNITS
D WH 1 09 S 4 -1 PD WH 1 09 S 4 -1 P
VOLTAGE
L = 115V-1 PHASE-60HZ
P = 208/230-1 PHASE-60HZ
MINOR DESIGN SEQUENCE
1 = 1ST REVISION
REFRIGERANT TYPE
4 = R410A
COOLING EFFICIENCY
S = STANDARD EFFICIENCY
SERIES TYPE
D = DUCTLESS SYSTEM
UNIT TYPE
WH = WALL MOUNT
MAJOR DESIGN SEQUENCE
1 = 1ST GENERATION
NOMINAL COOLING CAPACITY
09 = .75 TONS
12 = 1 TONS
18 = 1.5 TONS
24 = 2 TONS
36 = 3 TONS
WALL-MOUNTED INDOOR UNITS
