Allied 4DHV Mini-Split Series - Specifications; Outdoor Units

508067-01 Issue 2016 Page 3 of 75
Model Number 4DHV1S09S 4DHV1S12S 4DHV1S18S 4DHV1S24S 4DHV1S36S
Nominal Size- Tons 0.75 1 1.5 2 3
Ambient
Temp.
Operating
Range-°F
Cooling 5 - 122 -13 - 122
Heating 5 - 86 -13 - 86
Sound Data dBA 52 55 57.5 58 59
Refrigerant
Charge Furnished
(R410a) - oz.
1lb. 14 oz. 2lbs. 12 oz. 3lbs. 15 oz. 7 lbs. 8 oz.
Max Line Length - ft. 25
Charge Required/
Additional Ft. - oz.
0.16 0.32
Compressor
Type (1) Rotary
Refrigerant Oil Type Ester Oil VG74
Refrigerant Oil Charge
- Oz.
10.5 14.9 22.7
Connections
- in.
Liquid/Gas pipe (are) 1/4” / 3/8” 1/4” / 1/2” 3/8” / 5/8”
Maximum refrigerant
pipe length - ft.
82 98 213
Max. Di󰀨erence in level
of indoor unit - ft.
33 66 98
Outdoor Fan
(No.) Diameter - in. (1) 16-3/4 (1) 16-7/8 (1) 19-1/4 (1) 17
Total air volume - cfm 1175 1825 2130
rpm 800 / 650
800 / 650 (115V)
800 / 750 / 650
(208/230V)
800 / 750 / 650 900
Outdoor Coil
Number of rows 1 2 3
Fins per inch 21 18
Fin type Hydrophilic Aluminum
Tube outside diameter
- in.
1/4 5/16
Tube Type Ried Copper Tubing
Net face area - sq. ft. 4.04 4.72 4.67 5.12 8.13
Application area - sq. ft. 129 - 189 172 - 252 251 - 368 330 - 484 515 - 755
Design
Pressure
PSIG 550/340
Net/Shipping
Weight (lbs.)
115V 67 / 72 71 / 77 --- --- ---
208/230V 67 / 72 67 / 73 80 / 86 106 / 113 146 / 158
Electrical Data
Electrical
Char. - 60 Hz -
1 Phase
115V 208/230V 115V 208/230V 208/230V 208/230V 208/230V
Maximum Overcurrent
Protection (amps)
20 15 20 15 20 25 35
Minimum Circuit
Ampacity
16 10 15 20 25
Compressor rated Load
Amps
11.5 6.4 10.1 6.8 10 15 17
Outdoor Fan
Motor
Rated Load Amps 0.6 0.5 0.55 0.45 0.5 0.6
Output - W 34 115 120
NOTE - Extremes of operating range are plus and minus 10% of line voltage.
1 HACR type circuit breaker or fuse.
2 Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
Specications - Outdoor Units
