NAMEPLATE
ENGINE
SPEED
SENSOR
ASSEMBLY PADS
V07359
BREATHER
TO COOLER
NOTE: Inch Series Threads
FROM COOLER
NOTE: Inch Series Threads
RETARDER CONNECTOR
FEEDTHROUGH
HARNESS
CONNECTOR
TEMPERATURE SENSOR
SPEED SENSOR
TACHOGRAPH
Figure 3–2. 3000 Product Family Transmissions Disconnect Locations
