7–1. INSTALLATION INSPECTION LIST
Use this inspection list after transmission installation. As items are confirmed,
mark them off this list.
• Torque Values:
— All control module bolts—51–61 N•m (38–45 lb ft)
— Speed sensor bolts—24–29 N•m (18–21 lb ft)
— Flexplate-to-crankshaft hub bolts—Consult Engine Manufacturer
Specifications
— Flexplate-to-flexplate adapter bolts 12-bolt design— 33–39 N•m
(25–29 lb ft); 6-bolt design—63–73 N•m (46–54 lb ft)
— Fluid drain plug—25–32 N•m (18–24 lb ft)
— Fluid fill tube bracket—24–29 N•m (18–21 lb ft)
— Control module pressure taps—10–13 N•m (7–10 lb ft)
— Cooler fittings
#12, 34–47 N•m (25–35 lb ft)
#16, 54–68 N•m (40–50 lb ft)
#20, 68–81 N•m (50–60 lb ft)
— Cooler port cover bolts—51–61 N•m (38–45 lb ft)
— Expansion plug (prior to April 1997)—1–2 N•m (9–18 lb inch)
— Flexplate adapter-to-converter cover bolts—33–39 N•m (25–29 lb ft)
— Output flange bolt(s):
3000 Product Family transmission—30–35 N•m (22–26 lb ft)
4000 Product Family transmission—51–61 N•m (38–45 lb ft)
3000 and 4000 Product Families Transmissions built after
December 1, 1998—70–80 N•m (52–59 lb ft)
— PTO cover bolts—51–61 N•m (38–45 lb ft)
— PTO mounting bolts—51–61 N•m (38–45 lb ft)
— Breather—12–16 N•m (9–12 lb ft)
— PTO pressure hose to transmission—10–13 N•m (7–10 lb ft)
— Rear cover bolts—90–110 N•m (66–81 lb ft)
Section VII
INSPECTIONS AND
ADJUSTMENTS
76
