Allison Transmission 3000

V03350.08.00
OIL LEVEL SENSOR
P2 MODULE
P1 MODULE
CONVERTER MODULE • TURBINE • PUMP • LOCKUP CLUTCH/DAMPER • STATOR
CONVERTER HOUSING MODULE • CONVERTER HOUSING • PTO DRIVE GEAR
ROTATING CLUTCH MODULE • C1 CLUTCH • C2 CLUTCH • TURBINE SHAFT
CONTROL MODULE • ELECTRO-HYDRAULIC CONTROLS
MAIN SHAFT MODULE • MAIN SHAFT • P2 SUN • P3 SUN
MAIN HOUSING MODULE • MAIN HOUSING • C3 CLUTCH • C4 CLUTCH • C5 CLUTCH
FRONT SUPPORT/OIL PUMP MODULE • FRONT SUPPORT • OIL PUMP
REAR COVER MODULE • OUTPUT SHAFT • P3 • C5 PISTON
Figure 1–1. 3000 Product Family Transmission
with PTO—Cross Section
8
