5.4 - SELECTION OF THE GATE CONFIGURATION
DANGER
RISK OF IMPACT, CRUSHING, HOOKING AND ENTRAPMENT
• Set the DEF parameter according to the type of gate to be moved.
• Make all necessary adjustments and checks in accordance with all applicable local, regional and national
regulations and rules.
Failure to comply with these instructions will result in death or serious harm to persons and/
or property.
NOTE
• This procedure returns all parameters to their default value. Check the correct setting of all the param-
eters in case you want to use accessories and special features of this unit.
• Once the configuration is finished you need to do the learning of the strokes procedure.
Use the advanced parameter DEF to load dierent configurations of parameters, based on the maximum weight of the gate to move.
These configurations allow the gear motor to reach dierent adjustable speeds.
The control unit is configured with the DEF parameter at value 0.
Below is the table of parameters modified by the DEF parameter.
DEF GATE WEIGHT PARAMETER VALUES DEFAULT
0 MAX 2200 Kg
SPn
From 30 to 100 Hz 50 Hz
SPL
From 20 to 40 % of SPn 30 % of SPn
1 MAX 1200 Kg
SPn
From 30 to 110 Hz 60 Hz
SPL
From 20 to 40 % of SPn 25 % of SPn
2 MAX 800 Kg
SPn
From 30 to 130 Hz 60 Hz
SPL
From 20 to 40 % of SPn 25 % of SPn
3 MAX 500 Kg
SPn
From 30 to 150 Hz 75 Hz
SPL
From 20 to 40 % of SPn 20 % of SPn
