2.2 - TECHNICAL CHARACTERISTICS
Commercial name TRAKTOR T/I TRAKTOR M/I
The product complies with the following Directives and
Harmonized Standards
2014/53/EU
Construction of the device Electronic control device to be incorporated.
Purpose of the device Operating control device (non-safety)
Control unit CT TRAKTOR INVERTER installed on board
Software Class A
Power supply 230 Vac ± 10% 50/60 Hz
Radio transmission Rolling Code 433,92 MHz
Type of electric motor 3-phase Induction Motor 1-phase Induction Motor
Power consumption in standby mode mA 50
Maximum power consumption at startup A 10
Typical rolling current absorbed A 2 3,5
Electric motor power W 750 600
Maximum manoeuvring speed* m / min 16 15
Maximum thrust N 4700 3000
Maximum torque on the pinion Nm 180 115
Maximum weight of movable part* kg 2200
Service factor % 80
Maximum continuous duration min 8
Weight of the gear motor kg 9
Pinion module M4 Z19
Insulation class I
Degree of pollution 2
Acoustic pressure dB ≤ 70
Environmental operating conditions TA: -20...+55 °C RH max 90% without condensation
Conditions of transport and storage TA: -40...+70 °C RH max 90% without condensation
Degree of environmental protection IPx4
Thermally protected motor YES
Emergency release Release lever with key
NOTE
• The above values refer to a standard installation as follows: gate length 8 meters, with a total weight of
2200 kg uniformly distributed, installed according to the rule of art, free of mechanical conflicts and/ or
accidental friction, with four wheels for sliding of 200 mm diameter and moving along a rail installed in the
plane.
The values were measured at an ambient temperature of about 20 ºC.
• * Value referred to the gear motor in its factory configuration. See section "SELECTING THE GATE CON-
FIGURATION" for the values of the dierent configurations.
