Wireless-N Broadband Router User Guide
Connection Status - PPPoE
If using PPPoE (PPP over Ethernet), a screen like the following example will be displayed
when the "Connection Details" button is clicked.
Figure 42: PPPoE Status Screen
Data - PPPoE Screen
Connection Time
This indicates how long the current connection has been estab-
lished.
Connection to Server
This indicates whether or not the connection is currently estab-
lished.
Negotiation
This indicates the status of the Server login.
Authentication
This indicates the authentication currently used.
IP Address
The IP Address of this device, as seen by Internet users. This
address is allocated by your ISP (Internet Service Provider).
Network Mask
The Network Mask associated with the IP Address above.
Buttons
Connect
If not connected, establish a connection to your ISP.
Disconnect
If connected to your ISP, hang up the connection.
Close
Close this window.
54
