8
Chapter 8
Access Point Mode
This Chapter explains configuration and operation when in "Access Point".
Overview
There are two modes available on the Access Point screen.
• Router - In this mode, this device can provide shared Internet Access to all your LAN
users. Also, by default, it acts a DHCP Server, providing an IP address and related infor-
mation to all Wireless and LAN users.
• Access Point - The device links your Wireless Stations to your wired LAN. The Wireless
stations and devices on the wired LAN are then on the same network, and can communi-
cate with each other without regard for whether they are connected to the network via a
Wireless or wired connection.
This Chapter describes operation while in Access Point Mode.
Management Connections
• You need to have a DHCP Server on your LAN to provide IP addresses to the Wireless
clients using this Access Point.
• This AP must be a valid device on your LAN, to allow management connections. You
must assign a (fixed) IP address which is within the address range used on your LAN, but
not within the address range used by your DHCP server.
When you connect in future, just connect normally, using the IP address you assigned.
1. Start your WEB browser.
2. In the Address box, enter "HTTP://" and the current IP Address of the Wireless Access
Point, as in this example, which uses the Wireless Access Point's default IP Address:
HTTP://192.168.0.1
3. When prompted for the User name and Password, enter admin for the user name, and the
current password, as set on the password screen. (The password is the same regardless of
the mode.)
91
