4.2.2. Changing +/- prex for push or pull operations (P12)
By default pull forces applied to the measuring axle are displayed with
negative prefix and push forces accordingly as positive values (without
prefix). Submenu P12 allows to change the settings by pressing the
I-key.
[Push ( ) - Push (-)]
By pressing the S-key for 2 seconds you return to the operation level.
4.2.3. Display-refresh rate (P13)
The internal sensor captures forces with a frequency of 3,6 kHz. To
ensure the legibility of the display the display-refresh rate is limited
by default to 10 Hz. Submenu P13 allows to reduce this value further.
Press the I-key to select the desired frequency rate.
[Refresh rate: 1 - 2 - 3 - 5 - 10 Hz]
By pressing the S-key for 2 seconds you return to the operation level.
4.2.4. Automatic measuring stop – Auto-Stop for FMI-S (P14)
Measurements are stopped automatically when the measured values
are stable for 5 seconds, if you run the device without USB-cable. Sub-
menu P14 allows to adjust this period of time.
[Auto-Stop after: 5 - 10 - 20 - 30 seconds]
By pressing the S-key for 2 seconds you return to the operation level.
1
2
3
5
10
Example selecting parameter settings:
P13 - Display-refresh rate
The selected refresh rate flashes on the display
