Shared Call Appearances support three distinct types of hold behavior:
• Shared Hold - any handset using the Shared Call Appearance can retrieve the call on hold.
• Privacy Hold - only the handset that placed the call on hold can retrieve the call.
• Bridged Hold - the handset that placed the call on hold and one other handset that has the
same Shared Call Appearance can retrieve the call. Users initiate a Bridged Hold by placing an
Intercom call to the second party while the original call is active.
5.7.1 Call Routes
After creating Shared Call Appearance, it is selectable as a destination in any extension call route.
5.7.2 Phone LED Indicators
5.7.3 Outbound Calls
To seize a line locally for outbound calls, the press an idle Shared Call Appearance PFK and the PFK LED
changes to solid green. Listen for the dial tone, and place the outbound call. If the PFK LED is solid red,
the line is in use “remotely” on another assigned handset of the same Shared Call Appearance.
Note:
The Allworx server software does not support including a call on a shared hold in phone-hosted
conferences.
Color State Description
Off Idle No available calls on the Shared Call Appearance line. Users can access
the PFK for Line Seizure.
Solid Green In Use Locally The handset “owns” the Shared Call Appearance line. For Line Seizure,
dial tone is present and dialing can commence.
Fast Flashing Green Ringing An inbound call to the Shared Call Appearance is occurring. All parties
indicate ringing on the same Shared Call Appearance line.
Fast Flashing Red Ringing An inbound call to the Shared Call Appearance is occurring on a
handset set to Do Not Disturb (DND). User can answer call.
Slow Flashing Green On-hold Active call is on-hold (locally or remotely). Any Shared Call Appearance
participant can retrieve the call.
Slow Alternating Green
and Red
Privacy or
Bridged Hold
Active call is on-hold privately, and only the handset that held the call or
a bridged call can retrieve the call
Solid Red In Use
Remotely
The Shared Call Appearance line is in-use by a remote handset. Pressing
INFO and then the PFK shows who owns the Shared Call Appearance
line. The Shared Call Appearance line releases:
• when pressing the Shared Call Appearance PFK again on the phone
that seized it; or
• completing an active call on the Shared Call Appearance line.
