34
Dimensions pulsation damper ET
Exploded view pulsation damper ET
mm(inch) A B C D
ET10 NPT3/8” 85(3.3) 11(0.4) 79(3.1)
ET15 NPT1/2” 120(4.7) 12(0.5) 89(3.5)
ET25 NPT1” 170(6.7) 14(0.6) 133(5.2)
ET40 NPT1‐1/2” 220(8.7) 16(0.6) 162(6.4)
ET50 NPT2” 285(11.2) 18(0.7) 222(8.7)
