AdditionalhintsforpulsationdamperseriesET‐F(flangeversion)

Besidethescrewedpulsationdamperasstandardflangeversions (seriesET‐F) areavailablealso.Ingeneral,
pumpanddamperaredispatchedcompletelymounted.Still,theycanbepackedinseparateboxes,especially
forthebiggersizes.Ifso,use
theattachednuts,setscrews,washersanddiscs[11‐14]toflange thedamper
tothepump.






SparepartlistFlangeDamperET‐F  ET15‐F ET25‐F ET40‐F ET50‐F
Item Pc. Description Material Part‐No. Part‐No. Part‐No. Part‐No.
1 1
DamperhousingDIN,codeE.. PE 71518052 72518052 74018052 75018052
DamperhousingDIN,codeF.. PEconductive 71518056 72518056 74018056 75018056
DamperhousingDIN,codeT.. PTFE 71518069 72518069 74018069 75018069
DamperhousingDIN,codeU.. PTFEcond. 71518068 72518068 74018068 75018068
DamperhousingANSI,codeE..‐W PE 71528052 72528052 74028052 75028052
DamperhousingANSI,codeF..‐W PEconductive 71528056 72528056 74028056 75028056
DamperhousingANSI,codeT..‐W PTFE 71528069 72528069 74028069 75028069
DamperhousingANSI,codeU..‐W PTFEcond. 71528068 72528068 74028068 75028068
2 1
Diaphragm,code..E EPDM 11003172 11503172 12503172 14003172
Diaphragm,code..N NBR 11003170 11503170 12503170 14003170
Diaphragm,code..T PTFE 11003167 11503167 12503167 14003167
Diaphragm,code..T‐L PTFEcond.‐11503168 12503168 14003168
Diaphragm,code..T‐P PTFEmod.‐11503198 12503198 14003198
3 1 Damperhead,code.A. PA 71508153 72508153 74008153 75008153
  Damperhead,code.F. PEconductive 71508155 72508155 74008155 75008155
4 1 Tensiondisc 1.4301 71000822 71500822 72500822 74000822
5 1 Cover,code.A. PE 71000951 71500951 72500951 74000951
  Cover,code.F. PEconductive 71000955 71500955 72500955 74000955
6 * Housingbolt,cpl. 1.4301 71508322 72508322 74008322 75008322
7 1 Actuatorshaft 1.4301 11048222 11548222 12548222 14048222
8 3 Shaftpistonring,cpl. PTFE 10804164 11504164 12504164 14004164
9 1 Muffler PE 10864451 11564451 12564451 14064451
10 1
Flange‐O‐ring,centerhousingDIN,code..E
Flange‐O‐ring,centerhousingDIN,code..N
Flange‐O‐ring,centerhousingDIN,code..T
Flange‐O‐ring,centerhousingDIN,code..T‐V
EPDM
NBR
FEP/FKM
FKM
92063172
‐
92063159
92063175

93363272
93363271
93363259
93363275
95063372
95063371
95063359
95063375
96263472
96263471
96263459
96263475
Flange‐O‐ring,centerhousingANSI,code..E
Flange‐O‐ring,centerhousingANSI,code..N
Flange‐O‐ring,centerhousingANSI,code..T
Flange‐O‐ring,centerhousingANSI,code..T‐V
EPDM
NBR
FEP/FKM
FKM
92063172
‐
92063159
92063175
92358872
92358871
92358859
92358875
94061372
94061371
94061359
94061375
96263472
96263471
96263459
96263475
11 4 HexagonnutDIN934,DIN‐flange 1.4305 91210122 91210122 91610122 91610122
HexagonnutDIN934,ANSI‐flange 15‐6420‐03 15‐6420‐03 15‐6420‐03 15‐6430‐03
12 4 SetscrewDIN913,DIN‐flange 1.4305 91222522 91222522 91622622 91622722
Setscrew,ANSI‐flange91295522 91295522 91296522 91697022
13 4 SpringwasherDIN2093,DIN‐flange 1.4301 91215422 91215422 91615422 91615422
Springwasher,ANSI‐flange91415422 91415422 91415422 91615422
14 4 DiscDIN125,DIN‐flange 1.4301 91315122 91315122 91715122 91715122
DiscDIN125,ANSI‐flange91315122 91315122 91315122 91715122
*ET15‐F:4pieces;ET25‐FandET40‐F:6pieces;ET50‐F:8pieces
Allpartsinitalicsarenotproductwetted.
Pumpsize ET15 ET25 ET40 ET50
Torquevaluesforflangeconnections
Nm(ftlbs):
4(3) 5(3.7)
12
(8.9)
15
(11.1)
