Almatec E 08 - Page 36

36
DimensionspulsationdamperET‐F(flangeversion)














ExplodedviewpulsationdamperET‐F(flangeversion)


Subjecttochangewithoutnotice,2016/01(replaces2013/05)
ALMATECMaschinenbauGmbH
Carl‐Friedrich‐Gauss‐Str.5∙47475Kamp‐Lintfort∙Germany
Telephone++49.2842.9610∙Telefax++49.2842.96140
http://www.almatec.de∙e‐mail:info@almatec.de
mm(inch) A B C D E
ET15‐F 120(4.7) 95(3.7) 65(2.6) 14(0.6) 132(5.2)
ET25‐F 170(6.7) 115(4.5) 85(3.3) 14(0.6) 176(6.9)
ET40‐F 220(8.7) 150(5.9) 110(4.3) 18(0.7) 215(8.5)
ET50‐F 285(11.2) 165(6.5) 125(4.9) 18(0.7) 280(11.0)
