Shaw Almex Industries | 1.800.461.4351 | www.almex.com
15
49900-038
10. Troubleshooting
10.1. NO READING ON PLATEN SET 1 AND/OR PLATEN SET 2 TEMPERATURE INDICATORS
10.2. “ERR” DISPLAYED ON PLATEN SET 1 AND/OR PLATEN SET 2 TEMPERATURE INDICATORS
FAULT CORRECTION
10.2.1.
Platen not connected.
Err is displayed any time a platen cable is not connected. Ensure the platen
cables are connected and secured properly.
10.2.2. Loose connection in cable or platen Remove electrical connector insert from platen housing and tighten
connector. all connections.
10.2.3.
RTD temperature sensor is faulty.
Refer to the Maintenance Section in the Operator’s Manual for the Almex Press .
10.3. PLATENS NOT HEATING
FAULT CORRECTION
10.3.1. Power supply or cable is faulty. Ensure that the power cable is connected properly and that the
power supply is turned on.
10.3.2. Platen switch OFF. Turn platen switch to AUTO or MANUAL.
10.3.3. Temperature set improperly. Ensure that Temperature Set Point is correct.
10.3.4. No continuity between SG1 and platen.
Check power supply, fuses (inside panel) and cable connections.
10.3.5. Loose connection in SG1 control panel. Disconnect power supply, open the control cabinet and check
for loose wire connections.
10.3.6. Faulty RTD temperature sensor in platen. Refer to the Maintenance Section in the Operator’s Manual of
the Almex Press.
10.3.7. Faulty heating element in platen. Refer to the Maintenance Section in the Operator’s Manual of
the Almex Press.
10.3.8. Faulty Contactor in SG1 control panel.
Replace Contactor. (SEE SG1 PARTS LIST & SCHEMATIC DIAGRAM)
10.3.9. Loose connection in cable or
Remove electrical connector insert from housing and tighten all connections.
platen connector.
10.3.10. Faulty temperature controller in SG1
Replace Omron Temperature Controller.
control panel.
Revised - April 2014
10.1. NO READING ON PLATEN SET 1 AND/OR PLATEN SET 2 TEMPERATURE INDICATORS
FAULT CORRECTION
10.1.1. Power supply or cable is faulty. Ensure that the power cable is connected properly and that the power
supply is turned on.
10.1.2. Control circuit fuse has opened. Disconnect power, open control box and replace fuses.
See “9. Maintenance and Repair.”
FAULT CORRECTION
