Shaw Almex Industries | 1.800.461.4351 | www.almex.com
17
49900-038
Revised - April 2014
11. SG1 Parts List
ITEM QTY DESCRIPTON PART #
PER UNIT
Power - 60A Option 1 600 V, 60 A Connector Body - DSN60 11-PWR-INC-08
1 600 V, 60 A Handle - DSN60 11-PWR-INC-09
1 600 V, 60 A Handle - DSN60 (Australia only) 11-PWR-INC-13
4 600 V. 3-phase, 18 A midi-contactor 11-PWR-OUT-04
2 600 V, 3-phase 9 A midi-contactor 11-PWR-OUT-03
2 250 VAC, 1 A 5 x 20 mm fast-acting glass fuse 11-PWR-INC-13
6 600 VAC, 20 A CC-type fuse (In fuse blocks 1 - 4) 11-PWR-FUS-04
2 600 VAC, 9 A CC-type fuse (In fuse blocks 5 - 6) 11-PWR-FUS-02
2 600 VAC, 1 A FNQ-CC type fuse (In fuse block TX) 11-PWR-FUS-01
Power - 100A Option 1 Metric DR100 Poly Receptacle - 600 V 100 A 3P+G 11-PWR-INC-02
1 Metric DR100 Poly Handle with built-in draw grips 11-PWR-INC-03
4 600 V 3-PHASE, 32A midi-contactor 11-PWR-OUT-02
2 600 V, 3-phase 9 A midi-contactor 11-PWR-OUT-03
2 250 VAC, 1 A 5 x 20 mm fast-acting glass fuse 11-PWR-FUS-04
6 600 VAC, 30 A CC-type fuse (In fuse blocks 1 - 4) 11-PWR-FUS-03
2 600 VAC, 9 A CC-type fuse (In fuse blocks 5 - 6) 11-PWR-FUS-02
2 600 VAC, 1 A FNQ-CC type fuse (In fuse block TX) 11-PWR-FUS-01
Pressure Sensing 2 TPMS Wireless Pressure Sensors, 250 psi 11-WLS-PSN-02
2 Schrader Valve for TPMS Wireless Pressure Sensor 11-WLS-VLV-01
Thermocouple Temperature 8 10’ K-type Thermocouple extension cable, mini male, mini female 11-THR-OTH-02
Sensing Optional 8 12” length, 1/8” diameter K-type round probe, mini male 11-THR-OTH-01
Switchgear Networking 1 DeviceNet Female Terminator 11-NET-OPA-01
Optional 1 DeviceNet Male Terminator 11-NET-OPA-02
N-1 DeviceNet Chordset Straight Male/Female 8M (thin) 11-NET-OPA-03
1 DeviceNet Mini T-Connector 11-NET-OPA-04
Miscellaneous 1 DAP Draft Attack sealant caulking 11-STR-ENC-11
1 Dust Cover 11-STR-ENC-10
1 Silicon Gasket 11-STR-GAS-01
1 SG1 Protective Carrying Case 11-STR-ENC-12
Documentation 1 Operating Manual
1 Commissioning Report (QA)
