Alpha ESS SMILE5 - Mounting Space Requirements

Mounting
37
5.3.5. Mounting Space Requirements
 Reserve sufficient clearance around the product to ensure sufficient space for
installation, maintenance and heat dissipation.
 The side clearance is a recommendation. Keep the clearance as short as you can if
there is no influence to the operation and maintenance.
Recommended clearances for SMILE-Bat series
Recommended clearances for M4856-P
 Reserve sufficient clearance around the product to ensure sufficient space for
installation, maintenance and heat dissipation.
 The side clearance is a recommendation. Keep the clearance as short as you can if
there is no influence to the operation and maintenance.
 The clearance below is a ‘recommendation’ only and a minimum of 150 ~ 200 mm
off the ground was advisable to protect from submergence.
*Depending on quantity of the expansion batteries
